KW Coilover Kit V1 for Audi (FY/FYT) Q5 2.0L

SKU: 102100BY
Sale price$2,358.30 Regular price$3,369.00
Save $1,010.70

Please note: Not all items are kept in stock. Lead times may apply contact us to confirm availability before ordering.


KW's V1 is the entry model in its street coilover range, pairing height-adjustable struts with a damper setup that KW pre-configures for each vehicle. Ride height is continuously adjustable within the tested range using a dirt-resistant trapezoidal thread and composite collar, so it can still be changed easily years after fitting. Corrosion-resistant springs and bump stops are built for a long service life. This kit is developed for the Audi Q5 (FY) / Q5 Sportback (FYT) 2.0 quattro.

Key Features

  • Vehicle-specific, factory-set damping
  • Continuous ride height adjustment within the tested range
  • Trapezoidal thread with composite adjuster collar

Specifications

  • Version: V1
  • Damping: Fixed, vehicle-specific setting
  • Material: Stainless steel
  • Front lowering: 30–65 mm
  • Rear lowering: 35–65 mm
  • Front axle load: up to 1,250 kg
  • Rear axle load: up to 1,390 kg
  • Supplied as: Front axle coilover struts, rear axle springs with height adjustment + dampers
Note Not for vehicle class M1G.

Front axle load up to 1,250 kg; Rear axle load up to 1,390 kg.

For vehicles without electronic damper control.

See the Disclaimer tab for reference notes.

YearMakeModelVariantEngineDriveNotesRefs
2016+AudiQ5 (FY) FYB2.0 TDI quattroDiesel · 120 kW · 2.0L · 4-cylAll-Wheel DriveNot for vehicle class M1G2, 8, 62
2016+AudiQ5 (FY) FYB2.0 TDI quattroDiesel · 140 kW · 2.0L · 4-cylAll-Wheel DriveNot for vehicle class M1G2, 8, 62
2016+AudiQ5 (FY) FYB2.0 TFSI quattroPetrol · 183 kW · 2.0L · 4-cylAll-Wheel DriveNot for vehicle class M1G2, 8, 62
2016+AudiQ5 (FY) FYB2.0 TFSI quattroPetrol · 185 kW · 2.0L · 4-cylAll-Wheel DriveNot for vehicle class M1G2, 8, 62
2016+AudiQ5 (FY) FYB35 TDI quattroDiesel · 120 kW · 2.0L · 4-cylAll-Wheel DriveNot for vehicle class M1G2, 8, 62
2016+AudiQ5 (FY) FYB40 TDI Mild Hybrid quattroDiesel/Electric · 150 kW · 2.0L · 4-cylAll-Wheel DriveNot for vehicle class M1G2, 8, 62
2016+AudiQ5 (FY) FYB40 TDI quattroDiesel · 140 kW · 2.0L · 4-cylAll-Wheel DriveNot for vehicle class M1G2, 8, 62
2016+AudiQ5 (FY) FYB40 TFSI Mild Hybrid quattroPetrol/Electric · 150 kW · 2.0L · 4-cylAll-Wheel DriveNot for vehicle class M1G2, 8, 62
2016+AudiQ5 (FY) FYB45 TFSI Mild Hybrid quattroPetrol/Electric · 180 kW · 2.0L · 4-cylAll-Wheel DriveNot for vehicle class M1G2, 8, 62
2016+AudiQ5 (FY) FYB45 TFSI Mild Hybrid quattroPetrol/Electric · 195 kW · 2.0L · 4-cylAll-Wheel DriveNot for vehicle class M1G2, 8, 62
2020+AudiQ5 Sportback (FYT)40 TDI Mild Hybrid quattroDiesel/Electric · 150 kW · 2.0L · 4-cylAll-Wheel DriveNot for vehicle class M1G2, 8, 62
2020+AudiQ5 Sportback (FYT)40 TFSI Mild Hybrid quattroPetrol/Electric · 150 kW · 2.0L · 4-cylAll-Wheel DriveNot for vehicle class M1G2, 8, 62
2020+AudiQ5 Sportback (FYT)45 TFSI Mild Hybrid quattroPetrol/Electric · 195 kW · 2.0L · 4-cylAll-Wheel DriveNot for vehicle class M1G2, 8, 62
  • Note 2: Height adjustable front and rear axles (front axle threaded strut housings, rear axle adjustable springs + dampers).
  • Note 8: Not for vehicles with automatic self levelling control / air suspension.
  • Note 62: Not for cars with electronic damping.
