KW Coilover Kit V1 for BMW (G42) M240i / (G20) M340i / (G22) M440i

SKU: 102200CL
Sale price$2,302.30 Regular price$3,289.00
Save $986.70

Please note: Not all items are kept in stock. Lead times may apply contact us to confirm availability before ordering.


KW's V1 is the entry model in its street coilover range, pairing height-adjustable struts with a damper setup that KW pre-configures for each vehicle. Ride height is continuously adjustable within the tested range using a dirt-resistant trapezoidal thread and composite collar, so it can still be changed easily years after fitting. Corrosion-resistant springs and bump stops are built for a long service life. This kit is developed for the BMW M240i (G42) / M340i (G20) / M440i (G22).

Key Features

  • Vehicle-specific, factory-set damping
  • Continuous ride height adjustment within the tested range
  • Trapezoidal thread with composite adjuster collar

Specifications

  • Version: V1
  • Damping: Fixed, vehicle-specific setting
  • Material: Stainless steel
  • Front lowering: 40–60 mm
  • Rear lowering: 40–60 mm
  • Front axle load: 1,031–1,085 kg
  • Rear axle load: up to 1,245 kg
  • Supplied as: Front axle coilover struts, rear axle springs with height adjustment + dampers

Front axle load 1,031–1,085 kg; Rear axle load up to 1,245 kg.

For vehicles without electronic damper control.

See the Disclaimer tab for reference notes.

YearMakeModelVariantEngineDriveRefs
2018+BMW3 (G20, G80) G3L330 dDiesel · 195 kW · 3.0L · 6-cylRear-Wheel Drive2, 37
2018+BMW3 (G20, G80) G3LM 340 iPetrol · 285 kW · 3.0L · 6-cylRear-Wheel Drive2, 37
2018+BMW3 (G20, G80) G3L330 d Mild-HybridDiesel/Electric · 210 kW · 3.0L · 6-cylRear-Wheel Drive2, 37
2020+BMW4 Coupe (G22, G82)M 440 i Mild-HybridPetrol/Electric · 275 kW · 3.0L · 6-cylRear-Wheel Drive2, 37
2021+BMW2 Coupe (G42, G87)M240 iPetrol · 275 kW · 3.0L · 6-cylRear-Wheel Drive2, 37
  • Note 2: Height adjustable front and rear axles (front axle threaded strut housings, rear axle adjustable springs + dampers).
  • Note 37: For cars which have electronic dampers, make sure they are shut down. Specific electronical damper shut-downs are available from KW. Please check our accessories list.
