KW Coilover Kit V1 for BMW (E84) X1 xDrive35i

SKU: 10220068
Sale price$2,267.30 Regular price$3,239.00
Save $971.70

Please note: Not all items are kept in stock. Lead times may apply contact us to confirm availability before ordering.


KW's V1 is the entry model in its street coilover range, pairing height-adjustable struts with a damper setup that KW pre-configures for each vehicle. Ride height is continuously adjustable within the tested range using a dirt-resistant trapezoidal thread and composite collar, so it can still be changed easily years after fitting. Corrosion-resistant springs and bump stops are built for a long service life. This kit is developed for the BMW X1 xDrive35i (E84).

Key Features

  • Vehicle-specific, factory-set damping
  • Continuous ride height adjustment within the tested range
  • Trapezoidal thread with composite adjuster collar

Specifications

  • Version: V1
  • Damping: Fixed, vehicle-specific setting
  • Material: Stainless steel
  • Front lowering: 40–70 mm
  • Rear lowering: 40–70 mm
  • Front axle load: up to 1,030 kg
  • Rear axle load: up to 1,180 kg
  • Supplied as: Front axle coilover struts, rear axle springs with height adjustment + dampers

Front axle load up to 1,030 kg; Rear axle load up to 1,180 kg.

See the Disclaimer tab for reference notes.

YearMakeModelVariantEngineDriveRefs
2009–2015BMWX1 (E84) X1xDrive 28 iPetrol · 180 kW · 2.0L · 4-cylAll-Wheel Drive2
2009–2015BMWX1 (E84) X1xDrive 35 iPetrol · 225 kW · 3.0L · 6-cylAll-Wheel Drive2
2009–2015BMWX1 (E84) X1xDrive 20 iPetrol · 135 kW · 2.0L · 4-cylAll-Wheel Drive2
2009–2015BMWX1 (E84) X1xDrive 28 iPetrol · 194 kW · 3.0L · 6-cylAll-Wheel Drive2
2009–2015BMWX1 (E84) X1xDrive 28 iPetrol · 190 kW · 3.0L · 6-cylAll-Wheel Drive2
2009–2015BMWX1 (E84) X1xDrive 18 dDiesel · 105 kW · 2.0L · 4-cylAll-Wheel Drive2
2009–2015BMWX1 (E84) X1xDrive 20 dDiesel · 130 kW · 2.0L · 4-cylAll-Wheel Drive2
2009–2015BMWX1 (E84) X1xDrive 23 dDiesel · 150 kW · 2.0L · 4-cylAll-Wheel Drive2
2009–2015BMWX1 (E84) X1xDrive 20 dDiesel · 120 kW · 2.0L · 4-cylAll-Wheel Drive2
2009–2015BMWX1 (E84) X1xDrive 18 dDiesel · 100 kW · 2.0L · 4-cylAll-Wheel Drive2
2009–2015BMWX1 (E84) X1xDrive 25 iPetrol · 160 kW · 3.0L · 6-cylAll-Wheel Drive2
2009–2015BMWX1 (E84) X1xDrive 25 dDiesel · 160 kW · 2.0L · 4-cylAll-Wheel Drive2
2009–2015BMWX1 (E84) X1xDrive 20 dDiesel · 135 kW · 2.0L · 4-cylAll-Wheel Drive2
  • Note 2: Height adjustable front and rear axles (front axle threaded strut housings, rear axle adjustable springs + dampers).
