KW Coilover Kit V1 for Cupra (KH7) Ateca 2.0L 4Drive
Please note: Not all items are kept in stock. Lead times may apply contact us to confirm availability before ordering.

KW Coilover Kit V1 for Cupra (KH7) Ateca 2.0L 4Drive
Sale price$2,022.30
Regular price$2,889.00 (/)
KW's V1 is the entry model in its street coilover range, pairing height-adjustable struts with a damper setup that KW pre-configures for each vehicle. Ride height is continuously adjustable within the tested range using a dirt-resistant trapezoidal thread and composite collar, so it can still be changed easily years after fitting. Corrosion-resistant springs and bump stops are built for a long service life. This kit is developed for the Cupra Ateca (KH7) 2.0 4Drive.
Key Features
- Vehicle-specific, factory-set damping
- Continuous ride height adjustment within the tested range
- Trapezoidal thread with composite adjuster collar
Specifications
- Version: V1
- Damping: Fixed, vehicle-specific setting
- Material: Stainless steel
- Front lowering: 35–55 mm
- Rear lowering: 25–50 mm
- Front axle load: up to 1,120 kg
- Rear axle load: up to 1,110 kg
- Front strut diameter (vehicle): 55 mm
- Supplied as: Set - coilover struts for front axle, rear axle coming with springs / height adjustment, dampers separately, no cancellation kit for electronic damping
Front axle load up to 1,120 kg; Rear axle load up to 1,110 kg.
See the Disclaimer tab for reference notes.
| Year | Make | Model | Variant | Engine | Drive | Refs |
|---|---|---|---|---|---|---|
| 2018+ | Cupra | Ateca (KH7) 5FP | 2.0 TSI 4Drive | Petrol · 221 kW · 2.0L · 4-cyl | All-Wheel Drive | 2, 37, 57 |
- Note 2: Height adjustable front and rear axles (front axle threaded strut housings, rear axle adjustable springs + dampers).
- Note 37: For cars which have electronic dampers, make sure they are shut down. Specific electronical damper shut-downs are available from KW. Please check our accessories list.
- Note 57: Only for cars with a clamp diameter of 55mm on the front axle.
