KW Coilover Kit V1 for Cupra (KM7) Formentor VZ 4Drive
Please note: Not all items are kept in stock. Lead times may apply contact us to confirm availability before ordering.

KW Coilover Kit V1 for Cupra (KM7) Formentor VZ 4Drive
Sale price$2,022.30
Regular price$2,889.00 (/)
KW's V1 is the entry model in its street coilover range, pairing height-adjustable struts with a damper setup that KW pre-configures for each vehicle. Ride height is continuously adjustable within the tested range using a dirt-resistant trapezoidal thread and composite collar, so it can still be changed easily years after fitting. Corrosion-resistant springs and bump stops are built for a long service life. This kit is developed for the Cupra Formentor VZ (KM7) 4Drive.
Key Features
- Vehicle-specific, factory-set damping
- Continuous ride height adjustment within the tested range
- Trapezoidal thread with composite adjuster collar
Specifications
- Version: V1
- Damping: Fixed, vehicle-specific setting
- Material: Stainless steel
- Front lowering: 40–60 mm
- Rear lowering: 40–65 mm
- Front axle load: up to 1,130 kg
- Rear axle load: up to 1,090 kg
- Supplied as: Set - coilover struts for front axle, rear axle coming with springs / height adjustment, dampers separately, no cancellation kit for electronic damping
Front axle load up to 1,130 kg; Rear axle load up to 1,090 kg.
See the Disclaimer tab for reference notes.
| Year | Make | Model | Variant | Engine | Drive | Refs |
|---|---|---|---|---|---|---|
| 2020+ | Cupra | Formentor (KM7, KMP) | 2.0 TDI 4Drive | Diesel · 110 kW · 2.0L · 4-cyl | All-Wheel Drive | 2, 37 |
| 2020+ | Cupra | Formentor (KM7, KMP) | 2.0 TSI 4Drive | Petrol · 140 kW · 2.0L · 4-cyl | All-Wheel Drive | 2, 37 |
| 2020+ | Cupra | Formentor (KM7, KMP) | 2.0 TSI 4Drive | Petrol · 150 kW · 2.0L · 4-cyl | All-Wheel Drive | 2, 37 |
| 2020+ | Cupra | Formentor (KM7, KMP) | 2.0 TSI 4Drive | Petrol · 228 kW · 2.0L · 4-cyl | All-Wheel Drive | 2, 37 |
| 2020+ | Cupra | Formentor (KM7, KMP) | 2.0 VZ 4Drive | Petrol · 245 kW · 2.0L · 4-cyl | All-Wheel Drive | 2, 37 |
- Note 2: Height adjustable front and rear axles (front axle threaded strut housings, rear axle adjustable springs + dampers).
- Note 37: For cars which have electronic dampers, make sure they are shut down. Specific electronical damper shut-downs are available from KW. Please check our accessories list.
