KW Coilover Kit V1 for Mazda (DY) 2

SKU: 10275004
Sale price$1,805.30 Regular price$2,579.00
Save $773.70

Please note: Not all items are kept in stock. Lead times may apply contact us to confirm availability before ordering.


KW's V1 is the entry model in its street coilover range, pairing height-adjustable struts with a damper setup that KW pre-configures for each vehicle. Ride height is continuously adjustable within the tested range using a dirt-resistant trapezoidal thread and composite collar, so it can still be changed easily years after fitting. Corrosion-resistant springs and bump stops are built for a long service life. This kit is developed for the Mazda 2 (DY).

Key Features

  • Vehicle-specific, factory-set damping
  • Continuous ride height adjustment within the tested range
  • Trapezoidal thread with composite adjuster collar

Specifications

  • Version: V1
  • Damping: Fixed, vehicle-specific setting
  • Material: Stainless steel
  • Front lowering: 35–70 mm
  • Rear lowering: 25–55 mm
  • Front axle load: up to 815 kg
  • Rear axle load: up to 785 kg
  • Supplied as: Front axle coilover struts, rear axle springs with height adjustment + dampers

Front axle load up to 815 kg; Rear axle load up to 785 kg.

See the Disclaimer tab for reference notes.

YearMakeModelVariantEngineDriveRefs
2003–2007Mazda2 (DY)1.2 (DY3W)Petrol · 55 kW · 1.2L · 4-cylFront-Wheel Drive2, 94
2003–2007Mazda2 (DY)1.3 L (DY3W)Petrol · 67 kW · 1.3L · 4-cylFront-Wheel Drive2, 94
2003–2007Mazda2 (DY)1.4Petrol · 59 kW · 1.4L · 4-cylFront-Wheel Drive2, 94
2003–2007Mazda2 (DY)1.4 CDDiesel · 50 kW · 1.4L · 4-cylFront-Wheel Drive2, 94
2003–2007Mazda2 (DY)1.5 (DY5W)Petrol · 82 kW · 1.5L · 4-cylFront-Wheel Drive2, 94
2003–2007Mazda2 (DY)1.5 (DY5W)Petrol · 83 kW · 1.5L · 4-cylFront-Wheel Drive2, 94
2003–2007Mazda2 (DY)1.6Petrol · 74 kW · 1.6L · 4-cylFront-Wheel Drive2, 94
  • Note 2: Height adjustable front and rear axles (front axle threaded strut housings, rear axle adjustable springs + dampers).
  • Note 94: Specific damping variants only available while stocks last. For further information please send an email to sales@scuderia-autoart.com.
