KW Coilover Kit V1 for Volvo (533) C30 T5

SKU: 10267015
Sale price$2,435.30 Regular price$3,479.00
Save $1,043.70

Please note: Not all items are kept in stock. Lead times may apply contact us to confirm availability before ordering.


KW's V1 is the entry model in its street coilover range, pairing height-adjustable struts with a damper setup that KW pre-configures for each vehicle. Ride height is continuously adjustable within the tested range using a dirt-resistant trapezoidal thread and composite collar, so it can still be changed easily years after fitting. Corrosion-resistant springs and bump stops are built for a long service life. This kit is developed for the Volvo C30 T5 (533).

Key Features

  • Vehicle-specific, factory-set damping
  • Continuous ride height adjustment within the tested range
  • Trapezoidal thread with composite adjuster collar

Specifications

  • Version: V1
  • Damping: Fixed, vehicle-specific setting
  • Material: Stainless steel
  • Front lowering: 20–50 mm
  • Rear lowering: 30–60 mm
  • Front axle load: up to 1,080 kg
  • Rear axle load: up to 900 kg
  • Supplied as: Front axle coilover struts, rear axle springs with height adjustment + dampers

Front axle load up to 1,080 kg; Rear axle load up to 900 kg.

See the Disclaimer tab for reference notes.

YearMakeModelVariantEngineDriveRefs
2006–2013VolvoC30 (533, E, M)T5Petrol · 184 kW · 2.5L · 5-cylFront-Wheel Drive2
2006–2013VolvoC30 (533, E, M)1.6Petrol · 74 kW · 1.6L · 4-cylFront-Wheel Drive2
2006–2013VolvoC30 (533, E, M)1.8Petrol · 92 kW · 1.8L · 4-cylFront-Wheel Drive2
2006–2013VolvoC30 (533, E, M)2.0Petrol · 107 kW · 2.0L · 4-cylFront-Wheel Drive2
2006–2013VolvoC30 (533, E, M)2.4 iPetrol · 125 kW · 2.4L · 5-cylFront-Wheel Drive2
2006–2013VolvoC30 (533, E, M)T5Petrol · 162 kW · 2.5L · 5-cylFront-Wheel Drive2
2006–2013VolvoC30 (533, E, M)1.6 DDiesel · 80 kW · 1.6L · 4-cylFront-Wheel Drive2
2006–2013VolvoC30 (533, E, M)2.0 DDiesel · 100 kW · 2.0L · 4-cylFront-Wheel Drive2
2006–2013VolvoC30 (533, E, M)D5Diesel · 132 kW · 2.4L · 5-cylFront-Wheel Drive2
2006–2013VolvoC30 (533, E, M)T5Petrol · 169 kW · 2.5L · 5-cylFront-Wheel Drive2
2006–2013VolvoC30 (533, E, M)D5Diesel · 120 kW · 2.4L · 5-cylFront-Wheel Drive2
2006–2013VolvoC30 (533, E, M)D2Diesel · 84 kW · 1.6L · 4-cylFront-Wheel Drive2
2006–2013VolvoC30 (533, E, M)D3Diesel · 110 kW · 2.0L · 5-cylFront-Wheel Drive2
2006–2013VolvoC30 (533, E, M)D4Diesel · 130 kW · 2.0L · 5-cylFront-Wheel Drive2
  • Note 2: Height adjustable front and rear axles (front axle threaded strut housings, rear axle adjustable springs + dampers).
