KW Coilover Kit V1 for VW (MK3) Scirocco 1.4L TSI

SKU: 10280094
Sale price$2,022.30 Regular price$2,889.00
Save $866.70

Please note: Not all items are kept in stock. Lead times may apply contact us to confirm availability before ordering.


KW's V1 is the entry model in its street coilover range, pairing height-adjustable struts with a damper setup that KW pre-configures for each vehicle. Ride height is continuously adjustable within the tested range using a dirt-resistant trapezoidal thread and composite collar, so it can still be changed easily years after fitting. Corrosion-resistant springs and bump stops are built for a long service life. This kit is developed for the VW Scirocco 1.4 TSI (MK3).

Key Features

  • Vehicle-specific, factory-set damping
  • Continuous ride height adjustment within the tested range
  • Trapezoidal thread with composite adjuster collar

Specifications

  • Version: V1
  • Damping: Fixed, vehicle-specific setting
  • Material: Stainless steel
  • Front lowering: 20–55 mm
  • Rear lowering: 20–55 mm
  • Front axle load: up to 1,000 kg
  • Rear axle load: up to 780 kg
  • Front strut diameter (vehicle): 55 mm
  • Supplied as: Front axle coilover struts, rear axle springs with height adjustment + dampers

Front axle load up to 1,000 kg; Rear axle load up to 780 kg.

For vehicles without electronic damper control.

See the Disclaimer tab for reference notes.

YearMakeModelVariantEngineDriveRefs
2008–2018VWScirocco III (13, 137, 138)1.4 TSIPetrol · 92 kW · 1.4L · 4-cylFront-Wheel Drive2, 37, 57, 93
2008–2018VWScirocco III (13, 137, 138)1.4 TSIPetrol · 110 kW · 1.4L · 4-cylFront-Wheel Drive2, 37, 57, 93
2008–2018VWScirocco III (13, 137, 138)1.4 TSIPetrol · 96 kW · 1.4L · 4-cylFront-Wheel Drive2, 37, 57, 93
2008–2018VWScirocco III (13, 137, 138)1.4 TSIPetrol · 118 kW · 1.4L · 4-cylFront-Wheel Drive2, 37, 57, 93
2008–2018VWScirocco III (13, 137, 138)1.4 TSIPetrol · 90 kW · 1.4L · 4-cylFront-Wheel Drive2, 37, 57, 93
  • Note 2: Height adjustable front and rear axles (front axle threaded strut housings, rear axle adjustable springs + dampers).
  • Note 37: For cars which have electronic dampers, make sure they are shut down. Specific electronical damper shut-downs are available from KW. Please check our accessories list.
  • Note 57: Only for cars with a clamp diameter of 55mm on the front axle.
  • Note 93: To guarantee at maximum lowering the minimum clearance of the FA indicator light (350 mm) and day headlight (250 mm) beyond STVZO, they have to be modified.
