KW Coilover Kit V2 for Renault (RFB) Megane

SKU: 15290037
Sale price$3,362.05 Regular price$3,539.00
Save $176.95

Please note: Not all items are kept in stock. Lead times may apply contact us to confirm availability before ordering.


KW's V2 adds adjustable rebound damping to KW's height-adjustable coilover platform. The twin-tube dampers offer 16 clicks of rebound adjustment, so the setup can be made firmer or more comfortable without changing the compression damping. As with all KW coilovers, the base setting is developed for each vehicle on KW's 7-post rig and in road testing, including the Nürburgring Nordschleife. This kit is developed for the Renault Megane (RFB).

Key Features

  • Rebound damping adjustable in 16 clicks
  • Vehicle-specific base damper setting
  • Continuous ride height adjustment within the tested range

Specifications

  • Version: V2
  • Damping: Adjustable rebound
  • Material: Stainless steel
  • Front lowering: 10–40 mm
  • Rear lowering: 20–45 mm
  • Front axle load: up to 1,120 kg
  • Rear axle load: up to 1,000 kg
  • Supplied as: Front axle coilover struts, rear axle springs with height adjustment + dampers

Front axle load up to 1,120 kg; Rear axle load up to 1,000 kg.

See the Disclaimer tab for reference notes.

YearMakeModelVariantEngineDriveRefs
2015+RenaultMegane IV Hatchback (RFB, B9A/M/N_)1.2 TCe 130 (B9MR)Petrol · 97 kW · 1.2L · 4-cylFront-Wheel Drive2
2015+RenaultMegane IV Hatchback (RFB, B9A/M/N_)1.2 TCe 100 (B9MS)Petrol · 74 kW · 1.2L · 4-cylFront-Wheel Drive2
2015+RenaultMegane IV Hatchback (RFB, B9A/M/N_)1.6 TCe 205 (B9MV)Petrol · 151 kW · 1.6L · 4-cylFront-Wheel Drive2
2015+RenaultMegane IV Hatchback (RFB, B9A/M/N_)1.5 dCi 90 (B9A1)Diesel · 66 kW · 1.5L · 4-cylFront-Wheel Drive2
2015+RenaultMegane IV Hatchback (RFB, B9A/M/N_)1.5 dCi 110 (B9A3)Diesel · 81 kW · 1.5L · 4-cylFront-Wheel Drive2
2015+RenaultMegane IV Hatchback (RFB, B9A/M/N_)1.6 dCi 130 (B9A4)Diesel · 96 kW · 1.6L · 4-cylFront-Wheel Drive2
2015+RenaultMegane IV Hatchback (RFB, B9A/M/N_)1.6 dCi 165Diesel · 120 kW · 1.6L · 4-cylFront-Wheel Drive2
2015+RenaultMegane IV Hatchback (RFB, B9A/M/N_)1.6 16VPetrol · 84 kW · 1.6L · 4-cylFront-Wheel Drive2
2015+RenaultMegane IV Hatchback (RFB, B9A/M/N_)1.6 TCe 165Petrol · 121 kW · 1.6L · 4-cylFront-Wheel Drive2
2015+RenaultMegane IV Hatchback (RFB, B9A/M/N_)1.3 TCe 115 (B9N9)Petrol · 85 kW · 1.3L · 4-cylFront-Wheel Drive2
2015+RenaultMegane IV Hatchback (RFB, B9A/M/N_)1.3 TCe 140 (B9NB)Petrol · 103 kW · 1.3L · 4-cylFront-Wheel Drive2
2015+RenaultMegane IV Hatchback (RFB, B9A/M/N_)1.3 TCe 160 (B9NC)Petrol · 120 kW · 1.3L · 4-cylFront-Wheel Drive2
2015+RenaultMegane IV Hatchback (RFB, B9A/M/N_)1.5 Blue dCi 95 (B9A2, B9A6)Diesel · 70 kW · 1.5L · 4-cylFront-Wheel Drive2
2015+RenaultMegane IV Hatchback (RFB, B9A/M/N_)1.5 Blue dCi 115 (B9A6)Diesel · 85 kW · 1.5L · 4-cylFront-Wheel Drive2
2015+RenaultMegane IV Hatchback (RFB, B9A/M/N_)1.3 TCe 100 (B9N8)Petrol · 75 kW · 1.3L · 4-cylFront-Wheel Drive2
2015+RenaultMegane IV Hatchback (RFB, B9A/M/N_)1.8 Blue dCi 150 (B9A7)Diesel · 110 kW · 1.7L · 4-cylFront-Wheel Drive2
2015+RenaultMegane IV Hatchback (RFB, B9A/M/N_)1.3 TCe 160 (B9NC)Petrol · 117 kW · 1.3L · 4-cylFront-Wheel Drive2
2015+RenaultMegane IV Hatchback (RFB, B9A/M/N_)1.3 TCe 120Petrol · 89 kW · 1.3L · 4-cylFront-Wheel Drive2
2015+RenaultMegane IV Hatchback (RFB, B9A/M/N_)1.0 TCe 115 (B9MD, B9MW)Petrol · 84 kW · 1.0L · 3-cylFront-Wheel Drive2
2015+RenaultMegane IV Hatchback (RFB, B9A/M/N_)1.3 TCe 160 (B9NC)Petrol · 116 kW · 1.3L · 4-cylFront-Wheel Drive2
  • Note 2: Height adjustable front and rear axles (front axle threaded strut housings, rear axle adjustable springs + dampers).
