KW Coilover Kit V2 for Volvo (533) C30 T5
Please note: Not all items are kept in stock. Lead times may apply contact us to confirm availability before ordering.

KW Coilover Kit V2 for Volvo (533) C30 T5
Sale price$3,827.55
Regular price$4,029.00 (/)
KW's V2 adds adjustable rebound damping to KW's height-adjustable coilover platform. The twin-tube dampers offer 16 clicks of rebound adjustment, so the setup can be made firmer or more comfortable without changing the compression damping. As with all KW coilovers, the base setting is developed for each vehicle on KW's 7-post rig and in road testing, including the Nürburgring Nordschleife. This kit is developed for the Volvo C30 T5 (533).
Key Features
- Rebound damping adjustable in 16 clicks
- Vehicle-specific base damper setting
- Continuous ride height adjustment within the tested range
Specifications
- Version: V2
- Damping: Adjustable rebound
- Material: Stainless steel
- Front lowering: 20–50 mm
- Rear lowering: 30–60 mm
- Front axle load: up to 1,080 kg
- Rear axle load: up to 900 kg
- Supplied as: Front axle coilover struts, rear axle springs with height adjustment + dampers
Front axle load up to 1,080 kg; Rear axle load up to 900 kg.
See the Disclaimer tab for reference notes.
| Year | Make | Model | Variant | Engine | Drive | Refs |
|---|---|---|---|---|---|---|
| 2006–2013 | Volvo | C30 (533, E, M) | T5 | Petrol · 184 kW · 2.5L · 5-cyl | Front-Wheel Drive | 2 |
| 2006–2013 | Volvo | C30 (533, E, M) | 1.6 | Petrol · 74 kW · 1.6L · 4-cyl | Front-Wheel Drive | 2 |
| 2006–2013 | Volvo | C30 (533, E, M) | 1.8 | Petrol · 92 kW · 1.8L · 4-cyl | Front-Wheel Drive | 2 |
| 2006–2013 | Volvo | C30 (533, E, M) | 2.0 | Petrol · 107 kW · 2.0L · 4-cyl | Front-Wheel Drive | 2 |
| 2006–2013 | Volvo | C30 (533, E, M) | 2.4 i | Petrol · 125 kW · 2.4L · 5-cyl | Front-Wheel Drive | 2 |
| 2006–2013 | Volvo | C30 (533, E, M) | T5 | Petrol · 162 kW · 2.5L · 5-cyl | Front-Wheel Drive | 2 |
| 2006–2013 | Volvo | C30 (533, E, M) | 1.6 D | Diesel · 80 kW · 1.6L · 4-cyl | Front-Wheel Drive | 2 |
| 2006–2013 | Volvo | C30 (533, E, M) | 2.0 D | Diesel · 100 kW · 2.0L · 4-cyl | Front-Wheel Drive | 2 |
| 2006–2013 | Volvo | C30 (533, E, M) | D5 | Diesel · 132 kW · 2.4L · 5-cyl | Front-Wheel Drive | 2 |
| 2006–2013 | Volvo | C30 (533, E, M) | T5 | Petrol · 169 kW · 2.5L · 5-cyl | Front-Wheel Drive | 2 |
| 2006–2013 | Volvo | C30 (533, E, M) | D5 | Diesel · 120 kW · 2.4L · 5-cyl | Front-Wheel Drive | 2 |
| 2006–2013 | Volvo | C30 (533, E, M) | D2 | Diesel · 84 kW · 1.6L · 4-cyl | Front-Wheel Drive | 2 |
| 2006–2013 | Volvo | C30 (533, E, M) | D3 | Diesel · 110 kW · 2.0L · 5-cyl | Front-Wheel Drive | 2 |
| 2006–2013 | Volvo | C30 (533, E, M) | D4 | Diesel · 130 kW · 2.0L · 5-cyl | Front-Wheel Drive | 2 |
- Note 2: Height adjustable front and rear axles (front axle threaded strut housings, rear axle adjustable springs + dampers).
