KW Coilover Kit V2 for VW Beetle 1302 / 1303 - 3-Point Front Mount - Rear Coilovers
Please note: Not all items are kept in stock. Lead times may apply contact us to confirm availability before ordering.

KW Coilover Kit V2 for VW Beetle 1302 / 1303 - 3-Point Front Mount - Rear Coilovers
Sale price$3,542.55
Regular price$3,729.00 (/)
KW's V2 adds adjustable rebound damping to KW's height-adjustable coilover platform. The twin-tube dampers offer 16 clicks of rebound adjustment, so the setup can be made firmer or more comfortable without changing the compression damping. As with all KW coilovers, the base setting is developed for each vehicle on KW's 7-post rig and in road testing, including the Nürburgring Nordschleife. This kit is developed for the VW Beetle 1302 / 1303.
Key Features
- Rebound damping adjustable in 16 clicks
- Vehicle-specific base damper setting
- Continuous ride height adjustment within the tested range
Specifications
- Version: V2
- Damping: Adjustable rebound
- Material: Stainless steel
- Front lowering: 45–70 mm
- Rear lowering: 10–45 mm
- Front axle load: up to 540 kg
- Rear axle load: up to 760 kg
- Supplied as: Front axle + rear axle coilover struts
Note For vehicles with 3-point mounting on the front axle.
Front axle load up to 540 kg; Rear axle load up to 760 kg.
For vehicles with 3-point mounting on the FA.
See the Disclaimer tab for reference notes.
| Year | Make | Model | Variant | Engine | Drive | Refs |
|---|---|---|---|---|---|---|
| 1947–2003 | VW | Kaefer (11, 13) | 1302 1.2 (11) | Petrol · 25 kW · 1.2L · 4-cyl | Rear-Wheel Drive | 1, 61, 82 |
| 1947–2003 | VW | Kaefer (11, 13) | 1302 1.3 | Petrol · 29 kW · 1.3L · 4-cyl | Rear-Wheel Drive | 1, 61, 82 |
| 1947–2003 | VW | Kaefer (11, 13) | 1302 1.3 (11) | Petrol · 32 kW · 1.3L · 4-cyl | Rear-Wheel Drive | 1, 61, 82 |
| 1947–2003 | VW | Kaefer (11, 13) | 1302 1.6 | Petrol · 35 kW · 1.6L · 4-cyl | Rear-Wheel Drive | 1, 61, 82 |
| 1947–2003 | VW | Kaefer (11, 13) | 1302 1.6 (11) | Petrol · 37 kW · 1.6L · 4-cyl | Rear-Wheel Drive | 1, 61, 82 |
| 1947–2003 | VW | Kaefer (11, 13) | 1303 1.2 (13) | Petrol · 25 kW · 1.2L · 4-cyl | Rear-Wheel Drive | 1, 61, 82 |
| 1947–2003 | VW | Kaefer (11, 13) | 1303 1.3 (13) | Petrol · 32 kW · 1.3L · 4-cyl | Rear-Wheel Drive | 1, 61, 82 |
| 1947–2003 | VW | Kaefer (11, 13) | 1303 1.6 (13) | Petrol · 35 kW · 1.6L · 4-cyl | Rear-Wheel Drive | 1, 61, 82 |
| 1947–2003 | VW | Kaefer (11, 13) | 1303 LS, S 1.6 (13) | Petrol · 37 kW · 1.6L · 4-cyl | Rear-Wheel Drive | 1, 61, 82 |
- Note 1: Height adjustable on the front and rear axles (threaded strut housings).
- Note 61: Only for cars with 3-hole-bracket at front axle.
- Note 82: Production on demand. Please ask for delivery time.
