KW Coilover Kit V2 for VW (5C) Beetle 2.0L TDI / Beetle Convertible
Please note: Not all items are kept in stock. Lead times may apply contact us to confirm availability before ordering.

KW Coilover Kit V2 for VW (5C) Beetle 2.0L TDI / Beetle Convertible
Sale price$3,267.06
Regular price$3,439.00 (/)
KW's V2 adds adjustable rebound damping to KW's height-adjustable coilover platform. The twin-tube dampers offer 16 clicks of rebound adjustment, so the setup can be made firmer or more comfortable without changing the compression damping. As with all KW coilovers, the base setting is developed for each vehicle on KW's 7-post rig and in road testing, including the Nürburgring Nordschleife. This kit is developed for the VW Beetle 2.0 TDI / Beetle Convertible (5C).
Key Features
- Rebound damping adjustable in 16 clicks
- Vehicle-specific base damper setting
- Continuous ride height adjustment within the tested range
Specifications
- Version: V2
- Damping: Adjustable rebound
- Material: Stainless steel
- Front lowering: 35–65 mm
- Rear lowering: 40–70 mm
- Front axle load: 1,016–1,090 kg
- Rear axle load: up to 880 kg
- Front strut diameter (vehicle): 55 mm
- Supplied as: Front axle coilover struts, rear axle springs with height adjustment + dampers
Front axle load 1,016–1,090 kg; Rear axle load up to 880 kg.
See the Disclaimer tab for reference notes.
| Year | Make | Model | Variant | Engine | Drive | Refs |
|---|---|---|---|---|---|---|
| 2011–2019 | VW | Beetle (16, 5C1, 5C2) | 1.8 TSI | Petrol · 125 kW · 1.8L · 4-cyl | Front-Wheel Drive | 2, 57, 67 |
| 2011–2019 | VW | Beetle Convertible (16, 5C7, 5C8) | 2.0 TDI | Diesel · 110 kW · 2.0L · 4-cyl | Front-Wheel Drive | 2, 57, 67 |
| 2011–2019 | VW | Beetle (16, 5C1, 5C2) | 2.0 TDI | Diesel · 110 kW · 2.0L · 4-cyl | Front-Wheel Drive | 2, 57, 67 |
| 2011–2019 | VW | Beetle (16, 5C1, 5C2) | 2.0 TDI | Diesel · 81 kW · 2.0L · 4-cyl | Front-Wheel Drive | 2, 57, 67 |
| 2011–2019 | VW | Beetle (16, 5C1, 5C2) | 2.0 TSI | Petrol · 162 kW · 2.0L · 4-cyl | Front-Wheel Drive | 2, 57, 67 |
| 2011–2019 | VW | Beetle Convertible (16, 5C7, 5C8) | 2.0 TSI | Petrol · 162 kW · 2.0L · 4-cyl | Front-Wheel Drive | 2, 57, 67 |
| 2011–2019 | VW | Beetle Convertible (16, 5C7, 5C8) | 2.0 TDI | Diesel · 81 kW · 2.0L · 4-cyl | Front-Wheel Drive | 2, 57, 67 |
| 2011–2019 | VW | Beetle Convertible (16, 5C7, 5C8) | 1.8 TSI | Petrol · 125 kW · 1.8L · 4-cyl | Front-Wheel Drive | 2, 57, 67 |
| 2011–2019 | VW | Beetle (16, 5C1, 5C2) | 2.0 TFSI | Petrol · 147 kW · 2.0L · 4-cyl | Front-Wheel Drive | 2, 57, 67 |
| 2011–2019 | VW | Beetle Convertible (16, 5C7, 5C8) | 2.5 | Petrol · 125 kW · 2.5L · 5-cyl | Front-Wheel Drive | 2, 57, 67 |
| 2011–2019 | VW | Beetle (16, 5C1, 5C2) | 2.0 TSI | Petrol · 130 kW · 2.0L · 4-cyl | Front-Wheel Drive | 2, 57, 67 |
| 2011–2019 | VW | Beetle Convertible (16, 5C7, 5C8) | 2.0 TSI | Petrol · 130 kW · 2.0L · 4-cyl | Front-Wheel Drive | 2, 57, 67 |
| 2011–2019 | VW | Beetle Convertible (16, 5C7, 5C8) | 2.0 TFSI | Petrol · 157 kW · 2.0L · 4-cyl | Front-Wheel Drive | 2, 57, 67 |
| 2011–2019 | VW | Beetle (16, 5C1, 5C2) | 1.4 TSI | Petrol · 118 kW · 1.4L · 4-cyl | Front-Wheel Drive | 2, 57, 67 |
| 2011–2019 | VW | Beetle (16, 5C1, 5C2) | 1.6 TDI | Diesel · 77 kW · 1.6L · 4-cyl | Front-Wheel Drive | 2, 57, 67 |
| 2011–2019 | VW | Beetle (16, 5C1, 5C2) | 2.0 TDI | Diesel · 103 kW · 2.0L · 4-cyl | Front-Wheel Drive | 2, 57, 67 |
| 2011–2019 | VW | Beetle Convertible (16, 5C7, 5C8) | 1.4 TSI | Petrol · 118 kW · 1.4L · 4-cyl | Front-Wheel Drive | 2, 57, 67 |
| 2011–2019 | VW | Beetle Convertible (16, 5C7, 5C8) | 1.6 TDI | Diesel · 77 kW · 1.6L · 4-cyl | Front-Wheel Drive | 2, 57, 67 |
| 2011–2019 | VW | Beetle Convertible (16, 5C7, 5C8) | 2.0 TDI | Diesel · 103 kW · 2.0L · 4-cyl | Front-Wheel Drive | 2, 57, 67 |
| 2011–2019 | VW | Beetle Convertible (16, 5C7, 5C8) | 2.0 TFSI | Petrol · 147 kW · 2.0L · 4-cyl | Front-Wheel Drive | 2, 57, 67 |
| 2011–2019 | VW | Beetle (16, 5C1, 5C2) | 2.5 | Petrol · 125 kW · 2.5L · 5-cyl | Front-Wheel Drive | 2, 57, 67 |
| 2011–2019 | VW | Beetle (16, 5C1, 5C2) | 2.0 TSI | Petrol · 155 kW · 2.0L · 4-cyl | Front-Wheel Drive | 2, 57, 67 |
| 2011–2019 | VW | Beetle Convertible (16, 5C7, 5C8) | 2.0 TSI | Petrol · 155 kW · 2.0L · 4-cyl | Front-Wheel Drive | 2, 57, 67 |
- Note 2: Height adjustable front and rear axles (front axle threaded strut housings, rear axle adjustable springs + dampers).
- Note 57: Only for cars with a clamp diameter of 55mm on the front axle.
- Note 67: Dampers are adjusted by easily operating adjustment wheels. Rebound is only adjustable if the top of the piston rod is accessible. This will depend on the vehicle construction.
