KW Coilover Kit V2 for VW (MK4) Golf Estate / Skoda (1U) Octavia RS / VW (1J) Bora / Seat (1M) Toledo

SKU: 15282002
Sale price$2,744.56 Regular price$2,889.00
Save $144.44

Please note: Not all items are kept in stock. Lead times may apply contact us to confirm availability before ordering.


KW's V2 adds adjustable rebound damping to KW's height-adjustable coilover platform. The twin-tube dampers offer 16 clicks of rebound adjustment, so the setup can be made firmer or more comfortable without changing the compression damping. As with all KW coilovers, the base setting is developed for each vehicle on KW's 7-post rig and in road testing, including the Nürburgring Nordschleife. This kit is developed for the VW (MK4) Golf Estate / Skoda (1U) Octavia RS / VW (1J) Bora / Seat (1M) Toledo.

Key Features

  • Rebound damping adjustable in 16 clicks
  • Vehicle-specific base damper setting
  • Continuous ride height adjustment within the tested range

Specifications

  • Version: V2
  • Damping: Adjustable rebound
  • Material: Stainless steel
  • Front lowering: 35–65 mm
  • Rear lowering: 35–65 mm
  • Front axle load: up to 1,020 kg
  • Rear axle load: up to 1,080 kg
  • Supplied as: Front axle coilover struts, rear axle springs with height adjustment + dampers

Front axle load up to 1,020 kg; Rear axle load up to 1,080 kg.

References 2, 6, 7, 39. See the Disclaimer tab for reference notes.

YearMakeModelVariantEngineDriveRefs
1998–2013VWBora (1J, 1J2)1.6Petrol · 74 kW · 1.6L · 4-cylFront-Wheel Drive2, 6, 7, 39
1998–2013VWBora (1J, 1J2)2.0Petrol · 85 kW · 2.0L · 4-cylFront-Wheel Drive2, 6, 7, 39
1998–2013VWBora (1J, 1J2)2.3 V5Petrol · 110 kW · 2.3L · 5-cylFront-Wheel Drive2, 6, 7, 39
1998–2013VWBora (1J, 1J2)1.9 TDIDiesel · 66 kW · 1.9L · 4-cylFront-Wheel Drive2, 6, 7, 39
1998–2013VWBora (1J, 1J2)1.9 TDIDiesel · 81 kW · 1.9L · 4-cylFront-Wheel Drive2, 6, 7, 39
1998–2006SeatToledo Mk II (1M2)1.6Petrol · 74 kW · 1.6L · 4-cylFront-Wheel Drive2, 6, 7, 39
1998–2006SeatToledo Mk II (1M2)1.8 20VPetrol · 92 kW · 1.8L · 4-cylFront-Wheel Drive2, 6, 7, 39
1998–2006SeatToledo Mk II (1M2)2.3 V5Petrol · 110 kW · 2.3L · 5-cylFront-Wheel Drive2, 6, 7, 39
1998–2006SeatToledo Mk II (1M2)1.9 TDIDiesel · 66 kW · 1.9L · 4-cylFront-Wheel Drive2, 6, 7, 39
1998–2006SeatToledo Mk II (1M2)1.9 TDIDiesel · 81 kW · 1.9L · 4-cylFront-Wheel Drive2, 6, 7, 39
1998–2013VWBora (1J, 1J2)1.8Petrol · 92 kW · 1.8L · 4-cylFront-Wheel Drive2, 6, 7, 39
1998–2013VWBora (1J, 1J2)1.4 16VPetrol · 55 kW · 1.4L · 4-cylFront-Wheel Drive2, 6, 7, 39
1998–2013VWBora (1J, 1J2)1.9 SDIDiesel · 50 kW · 1.9L · 4-cylFront-Wheel Drive2, 6, 7, 39
1998–2010SkodaOctavia I Combi (1U5)1.8 TPetrol · 110 kW · 1.8L · 4-cylFront-Wheel Drive2, 6, 7, 39
1999–2006VWGolf IV Estate (1J_)1.8 TPetrol · 127 kW · 1.8L · 4-cylFront-Wheel Drive2, 6, 7, 39
1999–2006VWGolf IV Estate (1J_)2.8 V6Petrol · 130 kW · 2.8L · 6-cylFront-Wheel Drive2, 6, 7, 39
1996–2010SkodaOctavia I (1U2)1.8 TPetrol · 110 kW · 1.8L · 4-cylFront-Wheel Drive2, 6, 7, 39
1999–2006VWGolf IV Estate (1J_)1.4 16VPetrol · 55 kW · 1.4L · 4-cylFront-Wheel Drive2, 6, 7, 39
1999–2006VWGolf IV Estate (1J_)1.6Petrol · 74 kW · 1.6L · 4-cylFront-Wheel Drive2, 6, 7, 39
1999–2006VWGolf IV Estate (1J_)2.0Petrol · 85 kW · 2.0L · 4-cylFront-Wheel Drive2, 6, 7, 39
1999–2006VWGolf IV Estate (1J_)1.9 SDIDiesel · 50 kW · 1.9L · 4-cylFront-Wheel Drive2, 6, 7, 39
1999–2006VWGolf IV Estate (1J_)1.9 TDIDiesel · 66 kW · 1.9L · 4-cylFront-Wheel Drive2, 6, 7, 39
1999–2006VWGolf IV Estate (1J_)1.9 TDIDiesel · 81 kW · 1.9L · 4-cylFront-Wheel Drive2, 6, 7, 39
1998–2010SkodaOctavia I Combi (1U5)1.6Petrol · 55 kW · 1.6L · 4-cylFront-Wheel Drive2, 6, 7, 39
1999–2005VWBora Estate (1J, 1J6)2.0Petrol · 85 kW · 2.0L · 4-cylFront-Wheel Drive2, 6, 7, 39
1999–2005VWBora Estate (1J, 1J6)2.3 V5Petrol · 110 kW · 2.3L · 5-cylFront-Wheel Drive2, 6, 7, 39
1999–2005VWBora Estate (1J, 1J6)1.9 TDIDiesel · 85 kW · 1.9L · 4-cylFront-Wheel Drive2, 6, 7, 39
1999–2006VWGolf IV Estate (1J_)1.9 TDIDiesel · 85 kW · 1.9L · 4-cylFront-Wheel Drive2, 6, 7, 39
1999–2005VWBora Estate (1J, 1J6)1.6Petrol · 74 kW · 1.6L · 4-cylFront-Wheel Drive2, 6, 7, 39
1999–2005VWBora Estate (1J, 1J6)1.9 TDIDiesel · 81 kW · 1.9L · 4-cylFront-Wheel Drive2, 6, 7, 39
1996–2010SkodaOctavia I (1U2)2.0Petrol · 85 kW · 2.0L · 4-cylFront-Wheel Drive2, 6, 7, 39
1998–2010SkodaOctavia I Combi (1U5)2.0Petrol · 85 kW · 2.0L · 4-cylFront-Wheel Drive2, 6, 7, 39
1998–2013VWBora (1J, 1J2)1.9 TDIDiesel · 85 kW · 1.9L · 4-cylFront-Wheel Drive2, 6, 7, 39
1999–2005VWBora Estate (1J, 1J6)1.9 TDIDiesel · 66 kW · 1.9L · 4-cylFront-Wheel Drive2, 6, 7, 39
1999–2006VWGolf IV Estate (1J_)2.3 V5Petrol · 110 kW · 2.3L · 5-cylFront-Wheel Drive2, 6, 7, 39
1998–2006SeatToledo Mk II (1M2)1.4 16VPetrol · 55 kW · 1.4L · 4-cylFront-Wheel Drive2, 6, 7, 39
1999–2006VWGolf IV Estate (1J_)1.6 16VPetrol · 77 kW · 1.6L · 4-cylFront-Wheel Drive2, 6, 7, 39
1998–2013VWBora (1J, 1J2)1.6 16VPetrol · 77 kW · 1.6L · 4-cylFront-Wheel Drive2, 6, 7, 39
1999–2005VWBora Estate (1J, 1J6)1.6 16VPetrol · 77 kW · 1.6L · 4-cylFront-Wheel Drive2, 6, 7, 39
1996–2010SkodaOctavia I (1U2)1.4Petrol · 44 kW · 1.4L · 4-cylFront-Wheel Drive2, 6, 7, 39
1996–2010SkodaOctavia I (1U2)1.4 16VPetrol · 55 kW · 1.4L · 4-cylFront-Wheel Drive2, 6, 7, 39
1996–2010SkodaOctavia I (1U2)RS 1.8 TPetrol · 132 kW · 1.8L · 4-cylFront-Wheel Drive2, 6, 7, 39
1999–2006VWGolf IV Estate (1J_)1.9 TDIDiesel · 74 kW · 1.9L · 4-cylFront-Wheel Drive2, 6, 7, 39
1998–2013VWBora (1J, 1J2)1.9 TDIDiesel · 74 kW · 1.9L · 4-cylFront-Wheel Drive2, 6, 7, 39
1998–2013VWBora (1J, 1J2)1.9 TDIDiesel · 110 kW · 1.9L · 4-cylFront-Wheel Drive2, 6, 7, 39
1999–2005VWBora Estate (1J, 1J6)1.9 TDIDiesel · 74 kW · 1.9L · 4-cylFront-Wheel Drive2, 6, 7, 39
1999–2006VWGolf IV Estate (1J_)1.6Petrol · 75 kW · 1.6L · 4-cylFront-Wheel Drive2, 6, 7, 39
1998–2013VWBora (1J, 1J2)1.6Petrol · 75 kW · 1.6L · 4-cylFront-Wheel Drive2, 6, 7, 39
1999–2005VWBora Estate (1J, 1J6)1.6Petrol · 75 kW · 1.6L · 4-cylFront-Wheel Drive2, 6, 7, 39
1998–2013VWBora (1J, 1J2)2.3 V5Petrol · 125 kW · 2.3L · 5-cylFront-Wheel Drive2, 6, 7, 39
1999–2005VWBora Estate (1J, 1J6)2.3 V5Petrol · 125 kW · 2.3L · 5-cylFront-Wheel Drive2, 6, 7, 39
1998–2013VWBora (1J, 1J2)1.8 TPetrol · 110 kW · 1.8L · 4-cylFront-Wheel Drive2, 6, 7, 39
1999–2005VWBora Estate (1J, 1J6)1.8 TPetrol · 110 kW · 1.8L · 4-cylFront-Wheel Drive2, 6, 7, 39
1998–2006SeatToledo Mk II (1M2)1.6 16VPetrol · 77 kW · 1.6L · 4-cylFront-Wheel Drive2, 6, 7, 39
1996–2010SkodaOctavia I (1U2)1.6Petrol · 75 kW · 1.6L · 4-cylFront-Wheel Drive2, 6, 7, 39
1998–2010SkodaOctavia I Combi (1U5)1.4 16VPetrol · 55 kW · 1.4L · 4-cylFront-Wheel Drive2, 6, 7, 39
1998–2010SkodaOctavia I Combi (1U5)1.6Petrol · 75 kW · 1.6L · 4-cylFront-Wheel Drive2, 6, 7, 39
1999–2006VWGolf IV Estate (1J_)1.9 TDIDiesel · 96 kW · 1.9L · 4-cylFront-Wheel Drive2, 6, 7, 39
1998–2013VWBora (1J, 1J2)1.9 TDIDiesel · 96 kW · 1.9L · 4-cylFront-Wheel Drive2, 6, 7, 39
1999–2005VWBora Estate (1J, 1J6)1.9 TDIDiesel · 96 kW · 1.9L · 4-cylFront-Wheel Drive2, 6, 7, 39
1998–2006SeatToledo Mk II (1M2)2.3 V5 20VPetrol · 125 kW · 2.3L · 5-cylFront-Wheel Drive2, 6, 7, 39
1998–2006SeatToledo Mk II (1M2)1.9 TDIDiesel · 110 kW · 1.9L · 4-cylFront-Wheel Drive2, 6, 7, 39
1999–2005VWBora Estate (1J, 1J6)1.9 TDIDiesel · 110 kW · 1.9L · 4-cylFront-Wheel Drive2, 6, 7, 39
1999–2006VWGolf IV Estate (1J_)1.6 FSIPetrol · 81 kW · 1.6L · 4-cylFront-Wheel Drive2, 6, 7, 39
1998–2013VWBora (1J, 1J2)1.6 FSIPetrol · 81 kW · 1.6L · 4-cylFront-Wheel Drive2, 6, 7, 39
1999–2005VWBora Estate (1J, 1J6)1.6 FSIPetrol · 81 kW · 1.6L · 4-cylFront-Wheel Drive2, 6, 7, 39
1998–2013VWBora (1J, 1J2)1.8 TPetrol · 132 kW · 1.8L · 4-cylFront-Wheel Drive2, 6, 7, 39
1998–2010SkodaOctavia I Combi (1U5)RS 1.8 TPetrol · 132 kW · 1.8L · 4-cylFront-Wheel Drive2, 6, 7, 39
1999–2005VWBora Estate (1J, 1J6)1.8 TPetrol · 132 kW · 1.8L · 4-cylFront-Wheel Drive2, 6, 7, 39
1999–2006VWGolf IV Estate (1J_)1.8 TPetrol · 110 kW · 1.8L · 4-cylFront-Wheel Drive2, 6, 7, 39
1996–2010SkodaOctavia I (1U2)1.9 TDIDiesel · 96 kW · 1.9L · 4-cylFront-Wheel Drive2, 6, 7, 39
1998–2010SkodaOctavia I Combi (1U5)1.9 TDIDiesel · 96 kW · 1.9L · 4-cylFront-Wheel Drive2, 6, 7, 39
1999–2006VWGolf IV Estate (1J_)2.3 V5Petrol · 125 kW · 2.3L · 5-cylFront-Wheel Drive2, 6, 7, 39
1998–2006SeatToledo Mk II (1M2)1.9 TDIDiesel · 96 kW · 1.9L · 4-cylFront-Wheel Drive2, 6, 7, 39
1999–2005VWBora Estate (1J, 1J6)1.4 16VPetrol · 55 kW · 1.4L · 4-cylFront-Wheel Drive2, 6, 7, 39
1998–2006SeatToledo Mk II (1M2)1.8 20VTPetrol · 132 kW · 1.8L · 4-cylFront-Wheel Drive2, 6, 7, 39
1999–2006VWGolf IV Estate (1J_)1.9 TDIDiesel · 110 kW · 1.9L · 4-cylFront-Wheel Drive2, 6, 7, 39
1998–2010SkodaOctavia I Combi (1U5)1.9 TDIDiesel · 74 kW · 1.9L · 4-cylFront-Wheel Drive2, 6, 7, 39
1996–2010SkodaOctavia I (1U2)1.9 TDIDiesel · 74 kW · 1.9L · 4-cylFront-Wheel Drive2, 6, 7, 39
1998–2013VWBora (1J, 1J2)2.8 VR6Petrol · 130 kW · 2.8L · 6-cylFront-Wheel Drive2, 6, 7, 39
1998–2013VWBora (1J, 1J2)2.8 VR6Petrol · 147 kW · 2.8L · 6-cylFront-Wheel Drive2, 6, 7, 39
1998–2006SeatToledo Mk II (1M2)1.9 TDIDiesel · 74 kW · 1.9L · 4-cylFront-Wheel Drive2, 6, 7, 39
1996–2010SkodaOctavia I (1U2)1.6Petrol · 55 kW · 1.6L · 4-cylFront-Wheel Drive2, 6, 7, 39
1996–2010SkodaOctavia I (1U2)1.8Petrol · 92 kW · 1.8L · 4-cylFront-Wheel Drive2, 6, 7, 39
1996–2010SkodaOctavia I (1U2)1.9 TDIDiesel · 66 kW · 1.9L · 4-cylFront-Wheel Drive2, 6, 7, 39
1996–2010SkodaOctavia I (1U2)1.6Petrol · 74 kW · 1.6L · 4-cylFront-Wheel Drive2, 6, 7, 39
1996–2010SkodaOctavia I (1U2)1.9 SDIDiesel · 50 kW · 1.9L · 4-cylFront-Wheel Drive2, 6, 7, 39
1996–2010SkodaOctavia I (1U2)1.9 TDIDiesel · 81 kW · 1.9L · 4-cylFront-Wheel Drive2, 6, 7, 39
1998–2010SkodaOctavia I Combi (1U5)1.6Petrol · 74 kW · 1.6L · 4-cylFront-Wheel Drive2, 6, 7, 39
1998–2010SkodaOctavia I Combi (1U5)1.8 20VPetrol · 92 kW · 1.8L · 4-cylFront-Wheel Drive2, 6, 7, 39
1998–2010SkodaOctavia I Combi (1U5)1.9 SDIDiesel · 50 kW · 1.9L · 4-cylFront-Wheel Drive2, 6, 7, 39
1998–2010SkodaOctavia I Combi (1U5)1.9 TDIDiesel · 66 kW · 1.9L · 4-cylFront-Wheel Drive2, 6, 7, 39
1998–2010SkodaOctavia I Combi (1U5)1.9 TDIDiesel · 81 kW · 1.9L · 4-cylFront-Wheel Drive2, 6, 7, 39
  • Note 2: Height adjustable front and rear axles (front axle threaded strut housings, rear axle adjustable springs + dampers).
  • Note 6: When using original tyres, wheel offset spacers may be required.
  • Note 7: When lowering more than 40 mm, the anti-sway bar must be retrofitted. Anti-sway bar conversion set without Xenon headlights: KW Part No. 685 50 000 Anti-sway bar conversion set for vehicles with Xenon headlights: KW Part No. 685 50 005.
  • Note 39: For vehicles with a right drive shaft diameter of more than 42 mm, the maximum lowering tested (German technical inspection association) is reduced by 15 mm.
