KW Coilover Kit V3 for Audi (C8) A6 Avant / A7 Sportback - 53mm Front Strut - AWD

SKU: 352100CX
Sale price$4,863.05 Regular price$5,119.00
Save $255.95

Please note: Not all items are kept in stock. Lead times may apply contact us to confirm availability before ordering.


KW's V3 offers independent adjustment of rebound damping (16 clicks) and compression damping (12 clicks), technology carried over from KW's motorsport programme. KW develops a vehicle-specific base setup on its 7-post rig and in road and track testing, from which the damping can be tuned for comfort or sharper handling. Ride height is continuously adjustable within the tested range. This kit is developed for the Audi A6 Avant quattro / A7 Sportback quattro (C8).

Key Features

  • Rebound damping adjustable in 16 clicks
  • Compression damping adjustable in 12 clicks
  • Continuous ride height adjustment within the tested range

Specifications

  • Version: V3
  • Damping: Adjustable rebound and compression
  • Material: Stainless steel
  • Front lowering: 30–50 mm
  • Rear lowering: 30–50 mm
  • Front axle load: up to 1,310 kg
  • Rear axle load: up to 1,430 kg
  • Front strut diameter (vehicle): 53 mm
  • Supplied as: Front axle coilover struts, rear axle springs with height adjustment + dampers

Front axle load up to 1,310 kg; Rear axle load up to 1,430 kg.

For vehicles without electronic damper control.

See the Disclaimer tab for reference notes.

YearMakeModelVariantEngineDriveRefs
2018+AudiA6 Avant (F2) C8, 4A540 TDI Mild Hybrid quattroDiesel/Electric · 150 kW · 2.0L · 4-cylAll-Wheel Drive2, 8, 37, 67, 418
2018+AudiA6 Avant (F2) C8, 4A545 TDI Mild Hybrid quattroDiesel/Electric · 155 kW · 3.0L · 6-cylAll-Wheel Drive2, 8, 37, 67, 418
2018+AudiA6 Avant (F2) C8, 4A545 TDI Mild Hybrid quattroDiesel/Electric · 170 kW · 3.0L · 6-cylAll-Wheel Drive2, 8, 37, 67, 418
2018+AudiA6 Avant (F2) C8, 4A545 TDI Mild Hybrid quattroDiesel/Electric · 180 kW · 3.0L · 6-cylAll-Wheel Drive2, 8, 37, 67, 418
2018+AudiA6 Avant (F2) C8, 4A545 TDI quattroDiesel · 183 kW · 3.0L · 6-cylAll-Wheel Drive2, 8, 37, 67, 418
2018+AudiA6 Avant (F2) C8, 4A545 TFSI Mild Hybrid quattroPetrol/Electric · 180 kW · 2.0L · 4-cylAll-Wheel Drive2, 8, 37, 67, 418
2018+AudiA6 Avant (F2) C8, 4A545 TFSI Mild Hybrid quattroPetrol/Electric · 195 kW · 2.0L · 4-cylAll-Wheel Drive2, 8, 37, 67, 418
2018+AudiA6 Avant (F2) C8, 4A545 TFSI quattroPetrol · 195 kW · 2.0L · 4-cylAll-Wheel Drive2, 8, 37, 67, 418
2018+AudiA6 Avant (F2) C8, 4A550 TDI Mild Hybrid quattroDiesel/Electric · 210 kW · 3.0L · 6-cylAll-Wheel Drive2, 8, 37, 67, 418
2018+AudiA6 Avant (F2) C8, 4A555 TFSI Mild Hybrid quattroPetrol/Electric · 250 kW · 3.0L · 6-cylAll-Wheel Drive2, 8, 37, 67, 418
2017+AudiA7 Sportback (F2) 4KA40 TDI Mild Hybrid quattroDiesel/Electric · 150 kW · 2.0L · 4-cylAll-Wheel Drive2, 8, 37, 67, 418
2017+AudiA7 Sportback (F2) 4KA45 TDI Mild Hybrid quattroDiesel/Electric · 155 kW · 3.0L · 6-cylAll-Wheel Drive2, 8, 37, 67, 418
2017+AudiA7 Sportback (F2) 4KA45 TDI Mild Hybrid quattroDiesel/Electric · 170 kW · 3.0L · 6-cylAll-Wheel Drive2, 8, 37, 67, 418
2017+AudiA7 Sportback (F2) 4KA45 TDI Mild Hybrid quattroDiesel/Electric · 180 kW · 3.0L · 6-cylAll-Wheel Drive2, 8, 37, 67, 418
2017+AudiA7 Sportback (F2) 4KA45 TFSI Mild Hybrid quattroPetrol/Electric · 195 kW · 2.0L · 4-cylAll-Wheel Drive2, 8, 37, 67, 418
2017+AudiA7 Sportback (F2) 4KA45 TFSI Mild hybrid quattroPetrol/Electric · 180 kW · 2.0L · 4-cylAll-Wheel Drive2, 8, 37, 67, 418
2017+AudiA7 Sportback (F2) 4KA50 TDI Mild Hybrid quattroDiesel/Electric · 210 kW · 3.0L · 6-cylAll-Wheel Drive2, 8, 37, 67, 418
2017+AudiA7 Sportback (F2) 4KA55 TFSI Mild Hybrid quattroPetrol/Electric · 250 kW · 3.0L · 6-cylAll-Wheel Drive2, 8, 37, 67, 418
  • Note 2: Height adjustable front and rear axles (front axle threaded strut housings, rear axle adjustable springs + dampers).
  • Note 8: Not for vehicles with automatic self levelling control / air suspension.
  • Note 37: For cars which have electronic dampers, make sure they are shut down. Specific electronical damper shut-downs are available from KW. Please check our accessories list.
  • Note 67: Dampers are adjusted by easily operating adjustment wheels. Rebound is only adjustable if the top of the piston rod is accessible. This will depend on the vehicle construction.
  • Note 418: Only for cars with a clamp diameter of 53mm on the front axle.
