KW Coilover Kit V3 for Audi (F3/F3N) Q3 - AWD

SKU: 352100DJ
Sale price$4,359.55 Regular price$4,589.00
Save $229.45

Please note: Not all items are kept in stock. Lead times may apply contact us to confirm availability before ordering.


KW's V3 offers independent adjustment of rebound damping (16 clicks) and compression damping (12 clicks), technology carried over from KW's motorsport programme. KW develops a vehicle-specific base setup on its 7-post rig and in road and track testing, from which the damping can be tuned for comfort or sharper handling. Ride height is continuously adjustable within the tested range. This kit is developed for the Audi Q3 (F3) / Q3 Sportback (F3N) quattro.

Key Features

  • Rebound damping adjustable in 16 clicks
  • Compression damping adjustable in 12 clicks
  • Continuous ride height adjustment within the tested range

Specifications

  • Version: V3
  • Damping: Adjustable rebound and compression
  • Material: Stainless steel
  • Front lowering: 20–40 mm
  • Rear lowering: 20–45 mm
  • Front axle load: up to 1,210 kg
  • Rear axle load: up to 1,150 kg
  • Front strut diameter (vehicle): 55 mm
  • Supplied as: Front axle coilover struts, rear axle springs with height adjustment + dampers

Front axle load up to 1,210 kg; Rear axle load up to 1,150 kg.

For vehicles without electronic damper control.

See the Disclaimer tab for reference notes.

YearMakeModelVariantEngineDriveRefs
2018+AudiQ3 (F3) F3B35 TDI quattroDiesel · 110 kW · 2.0L · 4-cylAll-Wheel Drive2, 37, 57, 67
2018+AudiQ3 (F3) F3B40 TDI quattroDiesel · 140 kW · 2.0L · 4-cylAll-Wheel Drive2, 37, 57, 67
2018+AudiQ3 (F3) F3B40 TDI quattroDiesel · 142 kW · 2.0L · 4-cylAll-Wheel Drive2, 37, 57, 67
2018+AudiQ3 (F3) F3B40 TDI quattroDiesel · 147 kW · 2.0L · 4-cylAll-Wheel Drive2, 37, 57, 67
2018+AudiQ3 (F3) F3B40 TFSI quattroPetrol · 137 kW · 2.0L · 4-cylAll-Wheel Drive2, 37, 57, 67
2018+AudiQ3 (F3) F3B40 TFSI quattroPetrol · 140 kW · 2.0L · 4-cylAll-Wheel Drive2, 37, 57, 67
2018+AudiQ3 (F3) F3B45 TFSI quattroPetrol · 169 kW · 2.0L · 4-cylAll-Wheel Drive2, 37, 57, 67
2018+AudiQ3 (F3) F3B45 TFSI quattroPetrol · 170 kW · 2.0L · 4-cylAll-Wheel Drive2, 37, 57, 67
2018+AudiQ3 (F3) F3B45 TFSI quattroPetrol · 180 kW · 2.0L · 4-cylAll-Wheel Drive2, 37, 57, 67
2019+AudiQ3 Sportback (F3N)35 TDI quattroDiesel · 110 kW · 2.0L · 4-cylAll-Wheel Drive2, 37, 57, 67
2019+AudiQ3 Sportback (F3N)40 TDI quattroDiesel · 140 kW · 2.0L · 4-cylAll-Wheel Drive2, 37, 57, 67
2019+AudiQ3 Sportback (F3N)40 TDI quattroDiesel · 142 kW · 2.0L · 4-cylAll-Wheel Drive2, 37, 57, 67
2019+AudiQ3 Sportback (F3N)40 TDI quattroDiesel · 147 kW · 2.0L · 4-cylAll-Wheel Drive2, 37, 57, 67
2019+AudiQ3 Sportback (F3N)40 TFSI quattroPetrol · 140 kW · 2.0L · 4-cylAll-Wheel Drive2, 37, 57, 67
2019+AudiQ3 Sportback (F3N)45 TFSI quattroPetrol · 169 kW · 2.0L · 4-cylAll-Wheel Drive2, 37, 57, 67
2019+AudiQ3 Sportback (F3N)45 TFSI quattroPetrol · 180 kW · 2.0L · 4-cylAll-Wheel Drive2, 37, 57, 67
  • Note 2: Height adjustable front and rear axles (front axle threaded strut housings, rear axle adjustable springs + dampers).
  • Note 37: For cars which have electronic dampers, make sure they are shut down. Specific electronical damper shut-downs are available from KW. Please check our accessories list.
  • Note 57: Only for cars with a clamp diameter of 55mm on the front axle.
  • Note 67: Dampers are adjusted by easily operating adjustment wheels. Rebound is only adjustable if the top of the piston rod is accessible. This will depend on the vehicle construction.
