KW Coilover Kit V3 for Chevrolet (C7) Corvette Z06 / Corvette
Please note: Not all items are kept in stock. Lead times may apply contact us to confirm availability before ordering.

KW Coilover Kit V3 for Chevrolet (C7) Corvette Z06 / Corvette
Sale price$6,354.55
Regular price$6,689.00 (/)
KW's V3 offers independent adjustment of rebound damping (16 clicks) and compression damping (12 clicks), technology carried over from KW's motorsport programme. KW develops a vehicle-specific base setup on its 7-post rig and in road and track testing, from which the damping can be tuned for comfort or sharper handling. Ride height is continuously adjustable within the tested range. This kit is developed for the Chevrolet Corvette Z06 / Corvette (C7).
Key Features
- Rebound damping adjustable in 16 clicks
- Compression damping adjustable in 12 clicks
- Continuous ride height adjustment within the tested range
Specifications
- Version: V3
- Damping: Adjustable rebound and compression
- Material: Stainless steel
- Front lowering: 10–35 mm
- Rear lowering: 15–45 mm
- Front axle load: up to 930 kg
- Rear axle load: up to 1,020 kg
- Supplied as: Front axle + rear axle coilover struts
Front axle load up to 930 kg; Rear axle load up to 1,020 kg.
For vehicles without electronic damper control.
See the Disclaimer tab for reference notes.
| Year | Make | Model | Variant | Engine | Drive | Refs |
|---|---|---|---|---|---|---|
| 2013–2019 | Chevrolet | Corvette (C7) Y1BC | 6.2 | Petrol · 343 kW · 6.2L · 8-cyl | Rear-Wheel Drive | 1, 37, 67, 83 |
| 2013–2019 | Chevrolet | Corvette (C7) Y1BC | 6.2 | Petrol · 339 kW · 6.2L · 8-cyl | Rear-Wheel Drive | 1, 37, 67, 83 |
| 2013–2019 | Chevrolet | Corvette (C7) Y1BC | 6.2 | Petrol · 336 kW · 6.2L · 8-cyl | Rear-Wheel Drive | 1, 37, 67, 83 |
| 2013–2019 | Chevrolet | Corvette (C7) Y1BC | 6.2 Z06 | Petrol · 466 kW · 6.2L · 8-cyl | Rear-Wheel Drive | 1, 37, 67, 83 |
| 2013–2019 | Chevrolet | Corvette (C7) Y1BC | 6.2 Z06 | Petrol · 485 kW · 6.2L · 8-cyl | Rear-Wheel Drive | 1, 37, 67, 83 |
- Note 1: Height adjustable on the front and rear axles (threaded strut housings).
- Note 37: For cars which have electronic dampers, make sure they are shut down. Specific electronical damper shut-downs are available from KW. Please check our accessories list.
- Note 67: Dampers are adjusted by easily operating adjustment wheels. Rebound is only adjustable if the top of the piston rod is accessible. This will depend on the vehicle construction.
- Note 83: Standard leaf spring has to be dismantled!
