KW Coilover Kit V3 for Cupra (KH7) Ateca 2.0L 4Drive

SKU: 35281054
Sale price$4,340.55 Regular price$4,569.00
Save $228.45

Please note: Not all items are kept in stock. Lead times may apply contact us to confirm availability before ordering.


KW's V3 offers independent adjustment of rebound damping (16 clicks) and compression damping (12 clicks), technology carried over from KW's motorsport programme. KW develops a vehicle-specific base setup on its 7-post rig and in road and track testing, from which the damping can be tuned for comfort or sharper handling. Ride height is continuously adjustable within the tested range. This kit is developed for the Cupra Ateca (KH7) 2.0 4Drive.

Key Features

  • Rebound damping adjustable in 16 clicks
  • Compression damping adjustable in 12 clicks
  • Continuous ride height adjustment within the tested range

Specifications

  • Version: V3
  • Damping: Adjustable rebound and compression
  • Material: Stainless steel
  • Front lowering: 35–55 mm
  • Rear lowering: 25–50 mm
  • Front axle load: up to 1,120 kg
  • Rear axle load: up to 1,110 kg
  • Front strut diameter (vehicle): 55 mm
  • Supplied as: Set - coilover struts for front axle, rear axle coming with springs / height adjustment, dampers separately, no cancellation kit for electronic damping

Front axle load up to 1,120 kg; Rear axle load up to 1,110 kg.

See the Disclaimer tab for reference notes.

YearMakeModelVariantEngineDriveRefs
2018+CupraAteca (KH7) 5FP2.0 TSI 4DrivePetrol · 221 kW · 2.0L · 4-cylAll-Wheel Drive2, 37, 57, 67
  • Note 2: Height adjustable front and rear axles (front axle threaded strut housings, rear axle adjustable springs + dampers).
  • Note 37: For cars which have electronic dampers, make sure they are shut down. Specific electronical damper shut-downs are available from KW. Please check our accessories list.
  • Note 57: Only for cars with a clamp diameter of 55mm on the front axle.
  • Note 67: Dampers are adjusted by easily operating adjustment wheels. Rebound is only adjustable if the top of the piston rod is accessible. This will depend on the vehicle construction.
