KW Coilover Kit V3 Leveling for BMW (G21) M340i w/ Deactivation for Electronic Dampers

SKU: 35208200FD
Sale price$5,072.05 Regular price$5,339.00
Save $266.95

Please note: Not all items are kept in stock. Lead times may apply contact us to confirm availability before ordering.


KW Leveling suspension is aimed at drivers who want the handling and comfort of a KW coilover while keeping close to factory ground clearance. Progressive springs and a comfort-oriented base damper setting suit poor roads and urban speed humps, and the ride height can be set slightly below or above standard. The V3 dampers adjust separately in rebound and compression. This kit is developed for the BMW M340i Touring (G21) xDrive.

Key Features

  • Near-factory ride height
  • Separately adjustable rebound and compression damping
  • Progressive comfort springs

Specifications

  • Version: V3 Leveling
  • Damping: Adjustable rebound and compression
  • Material: Stainless steel
  • Front height change: -30 to -10 mm
  • Rear height change: -30 to -10 mm
  • Front axle load: 1,071–1,170 kg
  • Rear axle load: up to 1,360 kg
  • Supplied as: Front axle coilover struts, rear axle springs with height adjustment + dampers including cancellation kit for electronic damper control

Front axle load 1,071–1,170 kg; Rear axle load up to 1,360 kg.

For vehicles with electronic damper control.

See the Disclaimer tab for reference notes.

YearMakeModelVariantEngineDriveRefs
2019+BMW3 Touring (G21, G81) G3K320 d Mild-Hybrid xDriveDiesel/Electric · 120 kW · 2.0L · 4-cylAll-Wheel Drive2, 67, 88
2019+BMW3 Touring (G21, G81) G3K320 d Mild-Hybrid xDriveDiesel/Electric · 140 kW · 2.0L · 4-cylAll-Wheel Drive2, 67, 88
2019+BMW3 Touring (G21, G81) G3K330 d Mild-Hybrid xDriveDiesel/Electric · 210 kW · 3.0L · 6-cylAll-Wheel Drive2, 67, 88
2019+BMW3 Touring (G21, G81) G3K330 d xDriveDiesel · 195 kW · 3.0L · 6-cylAll-Wheel Drive2, 67, 88
2019+BMW3 Touring (G21, G81) G3KM 340 d Mild-Hybrid xDriveDiesel/Electric · 250 kW · 3.0L · 6-cylAll-Wheel Drive2, 67, 88
2019+BMW3 Touring (G21, G81) G3KM 340 i Mild-Hybrid xDrivePetrol/Electric · 275 kW · 3.0L · 6-cylAll-Wheel Drive2, 67, 88
2019+BMW3 Touring (G21, G81) G3KM 340 i xDrivePetrol · 275 kW · 3.0L · 6-cylAll-Wheel Drive2, 67, 88
2019+BMW3 Touring (G21, G81) G3KM 340 i xDrivePetrol · 285 kW · 3.0L · 6-cylAll-Wheel Drive2, 67, 88
2019+BMW3 Touring (G21, G81) G3KM 340 i xDrivePetrol/Electric · 288 kW · 3.0L · 6-cylAll-Wheel Drive2, 67, 88
  • Note 2: Height adjustable front and rear axles (front axle threaded strut housings, rear axle adjustable springs + dampers).
  • Note 67: Dampers are adjusted by easily operating adjustment wheels. Rebound is only adjustable if the top of the piston rod is accessible. This will depend on the vehicle construction.
  • Note 88: Electronic damping control has to be deactivated. Deactivation kit is included in the delivery.
