Part Number: 152501TPC

2015Ð2020 Ford F-150 4WD, 6Ð7 inch lift

Belltech coilover lift kits are engineered in the United States to deliver outstanding ride quality, handling and durability. This adjustable 6Ð7 inch system achieves lift without rack correction thanks to a proprietary progressive steering stop that prevents lower control arm interference at full lock and droop.

The front features height-adjustable coilovers with large 60 mm damper bodies and 35 mm independent rebound and compression valves for precise, consistent damping. A large main spring and helper spring are cold-formed from high-tensile steel and powder-coated for longevity, complemented by a progressive polymer bump stop.

Purpose-built spindles improve strength and reduce weight while keeping ball joint angles within spec. Steering angle is maintained for a factory-like turning radius. A 1/4 inch laser-cut skid plate protects the front differential, and high-clearance crossmembers, compression arms and a billet aluminium driveshaft spacer enhance strength and driveline geometry.

Rear lift blocks and longer heavy-duty U-bolts level the stance, re-centre the wheel in the arch and optimise pinion angle to help prevent driveshaft vibration. Vehicle-specific Trail Performance rear shocks with 55 mm damper bodies increase oil capacity for consistent damping and a smooth ride.

Tyre and wheel combinations

• 35_12.50 with 18_9 or 20_9 and 4.5Ð5 inch backspacing
• 37_12.50 with 20_9 and 5.5Ð5.75 inch backspacing
• 35_12.50 with 20_9 and 4.5Ð5.75 inch backspacing

High-grade hardware and brake-line relocation brackets are included. Belltech lift kits undergo rigorous testing to ensure performance in demanding conditions.
