KW Coilover Kit V1 for Audi (8U) RS Q3 / Q3 / VW (5N) Tiguan

SKU: 10280077
Sale price$2,113.30 Regular price$3,019.00
Save $905.70

Please note: Not all items are kept in stock. Lead times may apply contact us to confirm availability before ordering.


KW's V1 is the entry model in its street coilover range, pairing height-adjustable struts with a damper setup that KW pre-configures for each vehicle. Ride height is continuously adjustable within the tested range using a dirt-resistant trapezoidal thread and composite collar, so it can still be changed easily years after fitting. Corrosion-resistant springs and bump stops are built for a long service life. This kit is developed for the Audi RS Q3 / Q3 (8U) / VW Tiguan (5N).

Key Features

  • Vehicle-specific, factory-set damping
  • Continuous ride height adjustment within the tested range
  • Trapezoidal thread with composite adjuster collar

Specifications

  • Version: V1
  • Damping: Fixed, vehicle-specific setting
  • Material: Stainless steel
  • Front lowering: 30–60 mm
  • Rear lowering: 40–70 mm
  • Front axle load: up to 1,200 kg
  • Rear axle load: up to 1,170 kg
  • Front strut diameter (vehicle): 55 mm
  • Supplied as: Front axle coilover struts, rear axle springs with height adjustment + dampers
Note For cars without electronic damping.

Front axle load up to 1,200 kg; Rear axle load up to 1,170 kg.

For vehicles without electronic damper control.

See the Disclaimer tab for reference notes.

YearMakeModelVariantEngineDriveNotesRefs
2011–2020AudiQ3 (8U) 8UB, 8UG1.4 TFSIPetrol · 92 kW · 1.4L · 4-cylFront-Wheel DriveFor cars without electronic damping2, 57, 62
2011–2020AudiQ3 (8U) 8UB, 8UG1.4 TSIPetrol · 110 kW · 1.4L · 4-cylFront-Wheel DriveFor cars without electronic damping2, 57, 62
2011–2020AudiQ3 (8U) 8UB, 8UG2.0 TDIDiesel · 88 kW · 2.0L · 4-cylFront-Wheel DriveFor cars without electronic damping2, 57, 62
2011–2020AudiQ3 (8U) 8UB, 8UG2.0 TDIDiesel · 100 kW · 2.0L · 4-cylFront-Wheel DriveFor cars without electronic damping2, 57, 62
2011–2020AudiQ3 (8U) 8UB, 8UG2.0 TDIDiesel · 103 kW · 2.0L · 4-cylFront-Wheel DriveFor cars without electronic damping2, 57, 62
2011–2020AudiQ3 (8U) 8UB, 8UG2.0 TDIDiesel · 110 kW · 2.0L · 4-cylFront-Wheel DriveFor cars without electronic damping2, 57, 62
2011–2020AudiQ3 (8U) 8UB, 8UG2.0 TDIDiesel · 130 kW · 2.0L · 4-cylFront-Wheel DriveFor cars without electronic damping2, 57, 62
2011–2020AudiQ3 (8U) 8UB, 8UG2.0 TDIDiesel · 135 kW · 2.0L · 4-cylFront-Wheel DriveFor cars without electronic damping2, 57, 62
2011–2020AudiQ3 (8U) 8UB, 8UG2.0 TDI quattroDiesel · 103 kW · 2.0L · 4-cylAll-Wheel DriveFor cars without electronic damping2, 57, 62
2011–2020AudiQ3 (8U) 8UB, 8UG2.0 TDI quattroDiesel · 110 kW · 2.0L · 4-cylAll-Wheel DriveFor cars without electronic damping2, 57, 62
2011–2020AudiQ3 (8U) 8UB, 8UG2.0 TDI quattroDiesel · 120 kW · 2.0L · 4-cylAll-Wheel DriveFor cars without electronic damping2, 57, 62
2011–2020AudiQ3 (8U) 8UB, 8UG2.0 TDI quattroDiesel · 130 kW · 2.0L · 4-cylAll-Wheel DriveFor cars without electronic damping2, 57, 62
2011–2020AudiQ3 (8U) 8UB, 8UG2.0 TDI quattroDiesel · 135 kW · 2.0L · 4-cylAll-Wheel DriveFor cars without electronic damping2, 57, 62
2011–2020AudiQ3 (8U) 8UB, 8UG2.0 TFSIPetrol · 132 kW · 2.0L · 4-cylFront-Wheel DriveFor cars without electronic damping2, 57, 62
2011–2020AudiQ3 (8U) 8UB, 8UG2.0 TFSIPetrol · 147 kW · 2.0L · 4-cylFront-Wheel DriveFor cars without electronic damping2, 57, 62
2011–2020AudiQ3 (8U) 8UB, 8UG2.0 TFSI quattroPetrol · 125 kW · 2.0L · 4-cylAll-Wheel DriveFor cars without electronic damping2, 57, 62
2011–2020AudiQ3 (8U) 8UB, 8UG2.0 TFSI quattroPetrol · 132 kW · 2.0L · 4-cylAll-Wheel DriveFor cars without electronic damping2, 57, 62
2011–2020AudiQ3 (8U) 8UB, 8UG2.0 TFSI quattroPetrol · 147 kW · 2.0L · 4-cylAll-Wheel DriveFor cars without electronic damping2, 57, 62
2011–2020AudiQ3 (8U) 8UB, 8UG2.0 TFSI quattroPetrol · 155 kW · 2.0L · 4-cylAll-Wheel DriveFor cars without electronic damping2, 57, 62
2011–2020AudiQ3 (8U) 8UB, 8UG2.0 TFSI quattroPetrol · 162 kW · 2.0L · 4-cylAll-Wheel DriveFor cars without electronic damping2, 57, 62
2011–2020AudiQ3 (8U) 8UB, 8UGRS 2.5 quattroPetrol · 228 kW · 2.5L · 5-cylAll-Wheel DriveFor cars without electronic damping2, 57
2011–2020AudiQ3 (8U) 8UB, 8UGRS 2.5 quattroPetrol · 250 kW · 2.5L · 5-cylAll-Wheel DriveFor cars without electronic damping2, 57
2011–2020AudiQ3 (8U) 8UB, 8UGRS performance 2.5 quattroPetrol · 270 kW · 2.5L · 5-cylAll-Wheel DriveFor cars without electronic damping2, 57
2007–2018VWTiguan I (5N_)1.4 TSIPetrol · 90 kW · 1.4L · 4-cylFront-Wheel DriveFor cars without electronic damping2, 57
2007–2018VWTiguan I (5N_)1.4 TSIPetrol · 92 kW · 1.4L · 4-cylFront-Wheel DriveFor cars without electronic damping2, 57
2007–2018VWTiguan I (5N_)1.4 TSIPetrol · 110 kW · 1.4L · 4-cylFront-Wheel DriveFor cars without electronic damping2, 57
2007–2018VWTiguan I (5N_)1.4 TSIPetrol · 118 kW · 1.4L · 4-cylFront-Wheel DriveFor cars without electronic damping2, 57
2007–2018VWTiguan I (5N_)1.4 TSI 4motionPetrol · 110 kW · 1.4L · 4-cylAll-Wheel DriveFor cars without electronic damping2, 57
2007–2018VWTiguan I (5N_)1.4 TSI 4motionPetrol · 118 kW · 1.4L · 4-cylAll-Wheel DriveFor cars without electronic damping2, 57
2007–2018VWTiguan I (5N_)2.0 TDIDiesel · 81 kW · 2.0L · 4-cylFront-Wheel DriveFor cars without electronic damping2, 57
2007–2018VWTiguan I (5N_)2.0 TDIDiesel · 103 kW · 2.0L · 4-cylFront-Wheel DriveFor cars without electronic damping2, 57
2007–2018VWTiguan I (5N_)2.0 TDIDiesel · 110 kW · 2.0L · 4-cylFront-Wheel DriveFor cars without electronic damping2, 57
2007–2018VWTiguan I (5N_)2.0 TDI 4motionDiesel · 100 kW · 2.0L · 4-cylAll-Wheel DriveFor cars without electronic damping2, 57
2007–2018VWTiguan I (5N_)2.0 TDI 4motionDiesel · 103 kW · 2.0L · 4-cylAll-Wheel DriveFor cars without electronic damping2, 57
2007–2018VWTiguan I (5N_)2.0 TDI 4motionDiesel · 110 kW · 2.0L · 4-cylAll-Wheel DriveFor cars without electronic damping2, 57
2007–2018VWTiguan I (5N_)2.0 TDI 4motionDiesel · 120 kW · 2.0L · 4-cylAll-Wheel DriveFor cars without electronic damping2, 57
2007–2018VWTiguan I (5N_)2.0 TDI 4motionDiesel · 125 kW · 2.0L · 4-cylAll-Wheel DriveFor cars without electronic damping2, 57
2007–2018VWTiguan I (5N_)2.0 TDI 4motionDiesel · 130 kW · 2.0L · 4-cylAll-Wheel DriveFor cars without electronic damping2, 57
2007–2018VWTiguan I (5N_)2.0 TDI 4motionDiesel · 135 kW · 2.0L · 4-cylAll-Wheel DriveFor cars without electronic damping2, 57
2007–2018VWTiguan I (5N_)2.0 TFSIPetrol · 147 kW · 2.0L · 4-cylFront-Wheel DriveFor cars without electronic damping2, 57
2007–2018VWTiguan I (5N_)2.0 TFSI 4motionPetrol · 125 kW · 2.0L · 4-cylAll-Wheel DriveFor cars without electronic damping2, 57
2007–2018VWTiguan I (5N_)2.0 TFSI 4motionPetrol · 147 kW · 2.0L · 4-cylAll-Wheel DriveFor cars without electronic damping2, 57
2007–2018VWTiguan I (5N_)2.0 TSI 4motionPetrol · 132 kW · 2.0L · 4-cylAll-Wheel DriveFor cars without electronic damping2, 57
2007–2018VWTiguan I (5N_)2.0 TSI 4motionPetrol · 155 kW · 2.0L · 4-cylAll-Wheel DriveFor cars without electronic damping2, 57
  • Note 2: Height adjustable front and rear axles (front axle threaded strut housings, rear axle adjustable springs + dampers).
  • Note 37: For cars which have electronic dampers, make sure they are shut down. Specific electronical damper shut-downs are available from KW. Please check our accessories list.
  • Note 57: Only for cars with a clamp diameter of 55mm on the front axle.
  • Note 62: Not for cars with electronic damping.
