KW Coilover Kit V2 for Audi (8J) TT
Please note: Not all items are kept in stock. Lead times may apply contact us to confirm availability before ordering.

KW's V2 adds adjustable rebound damping to KW's height-adjustable coilover platform. The twin-tube dampers offer 16 clicks of rebound adjustment, so the setup can be made firmer or more comfortable without changing the compression damping. As with all KW coilovers, the base setting is developed for each vehicle on KW's 7-post rig and in road testing, including the Nürburgring Nordschleife. This kit is developed for the Audi TT (8J) FWD.
Key Features
- Rebound damping adjustable in 16 clicks
- Vehicle-specific base damper setting
- Continuous ride height adjustment within the tested range
Specifications
- Version: V2
- Damping: Adjustable rebound
- Material: Stainless steel
- Front lowering: 20–50 mm
- Rear lowering: 20–50 mm
- Front axle load: up to 965 kg
- Rear axle load: up to 870 kg
- Front strut diameter (vehicle): 55 mm
- Supplied as: Front axle coilover struts, rear axle springs with height adjustment + dampers
Front axle load up to 965 kg; Rear axle load up to 870 kg.
For vehicles without electronic damper control.
See the Disclaimer tab for reference notes.
| Year | Make | Model | Variant | Engine | Drive | Refs |
|---|---|---|---|---|---|---|
| 2006–2015 | Audi | TT (8J) 8J3 | 2.0 TFSI | Petrol · 149 kW · 2.0L · 4-cyl | Front-Wheel Drive | 2, 37, 57, 67 |
| 2006–2015 | Audi | TT (8J) 8J3 | 2.0 TFSI | Petrol · 147 kW · 2.0L · 4-cyl | Front-Wheel Drive | 2, 37, 57, 67 |
| 2006–2015 | Audi | TT (8J) 8J3 | 1.8 TFSI | Petrol · 118 kW · 1.8L · 4-cyl | Front-Wheel Drive | 2, 37, 57, 67 |
| 2006–2015 | Audi | TT (8J) 8J3 | 2.0 TFSI | Petrol · 155 kW · 2.0L · 4-cyl | Front-Wheel Drive | 2, 37, 57, 67 |
- Note 2: Height adjustable front and rear axles (front axle threaded strut housings, rear axle adjustable springs + dampers).
- Note 37: For cars which have electronic dampers, make sure they are shut down. Specific electronical damper shut-downs are available from KW. Please check our accessories list.
- Note 57: Only for cars with a clamp diameter of 55mm on the front axle.
- Note 67: Dampers are adjusted by easily operating adjustment wheels. Rebound is only adjustable if the top of the piston rod is accessible. This will depend on the vehicle construction.
