KW Coilover Kit V2 for Toyota (E12) Corolla TS / Corolla

SKU: 15256001
Sale price$3,286.05 Regular price$3,459.00
Save $172.95

Please note: Not all items are kept in stock. Lead times may apply contact us to confirm availability before ordering.


KW's V2 adds adjustable rebound damping to KW's height-adjustable coilover platform. The twin-tube dampers offer 16 clicks of rebound adjustment, so the setup can be made firmer or more comfortable without changing the compression damping. As with all KW coilovers, the base setting is developed for each vehicle on KW's 7-post rig and in road testing, including the Nürburgring Nordschleife. This kit is developed for the Toyota Corolla TS / Corolla (E12).

Key Features

  • Rebound damping adjustable in 16 clicks
  • Vehicle-specific base damper setting
  • Continuous ride height adjustment within the tested range

Specifications

  • Version: V2
  • Damping: Adjustable rebound
  • Material: Stainless steel
  • Front lowering: 30–60 mm
  • Rear lowering: 30–60 mm
  • Front axle load: up to 1,000 kg
  • Rear axle load: up to 970 kg
  • Supplied as: Front axle + rear axle coilover struts

Front axle load up to 1,000 kg; Rear axle load up to 970 kg.

See the Disclaimer tab for reference notes.

YearMakeModelVariantEngineDriveRefs
2001–2008ToyotaCorolla (_E12_)1.8 VVTL-i TS (ZZE123)Petrol · 140 kW · 1.8L · 4-cylFront-Wheel Drive1
2001–2008ToyotaCorolla (_E12_)1.8 (ZZE122_, ZZE122R)Petrol · 93 kW · 1.8L · 4-cylFront-Wheel Drive1
2001–2008ToyotaCorolla (_E12_)1.4 VVT-i (ZZE120_, ZZE120R)Petrol · 71 kW · 1.4L · 4-cylFront-Wheel Drive1
2001–2008ToyotaCorolla (_E12_)1.6 VVT-i (ZZE121_, ZZE121R)Petrol · 81 kW · 1.6L · 4-cylFront-Wheel Drive1
2001–2008ToyotaCorolla (_E12_)1.8 VVTL-i TS (ZZE123)Petrol · 141 kW · 1.8L · 4-cylFront-Wheel Drive1
2001–2008ToyotaCorolla (_E12_)2.0 D-4D (CDE120_, CDE120R)Diesel · 66 kW · 2.0L · 4-cylFront-Wheel Drive1
2001–2008ToyotaCorolla (_E12_)2.0 D-4D (CDE120R, CDE120L_)Diesel · 81 kW · 2.0L · 4-cylFront-Wheel Drive1
2000–2008ToyotaCorolla Saloon (_E12_)1.4 VVT-i (ZZE120_, ZZE120R)Petrol · 71 kW · 1.4L · 4-cylFront-Wheel Drive1
2000–2008ToyotaCorolla Saloon (_E12_)1.6 VVT-i (ZZE121_, ZZE121R)Petrol · 81 kW · 1.6L · 4-cylFront-Wheel Drive1
2001–2008ToyotaCorolla (_E12_)2.0 D-4D (CDE120R, CDE120L_)Diesel · 85 kW · 2.0L · 4-cylFront-Wheel Drive1
2000–2008ToyotaCorolla Saloon (_E12_)2.0 D-4D (CDE120_, CDE120R)Diesel · 66 kW · 2.0L · 4-cylFront-Wheel Drive1
2001–2008ToyotaCorolla (_E12_)1.4 D (NDE120_, NDE120R)Diesel · 66 kW · 1.4L · 4-cylFront-Wheel Drive1
2000–2008ToyotaCorolla Saloon (_E12_)1.4 D-4D (NDE120_, NDE120R)Diesel · 66 kW · 1.4L · 4-cylFront-Wheel Drive1
2001–2008ToyotaCorolla (_E12_)1.8 VVTL-i TS (ZZE123_, ZZE123R)Petrol · 165 kW · 1.8L · 4-cylFront-Wheel Drive1
2000–2008ToyotaCorolla Saloon (_E12_)1.8 (ZZE122)Petrol · 100 kW · 1.8L · 4-cylFront-Wheel Drive1
2000–2008ToyotaCorolla Saloon (_E12_)1.8 (ZZE122)Petrol · 96 kW · 1.8L · 4-cylFront-Wheel Drive1
2001–2008ToyotaCorolla (_E12_)1.8 VVTi (ZZE122_, ZZE122R)Petrol · 100 kW · 1.8L · 4-cylFront-Wheel Drive1
2000–2008ToyotaCorolla Saloon (_E12_)2.0 D-4D (CDE120_, CDE120R)Diesel · 85 kW · 2.0L · 4-cylFront-Wheel Drive1
2000–2008ToyotaCorolla Saloon (_E12_)1.8 (ZZE122)Petrol · 92 kW · 1.8L · 4-cylFront-Wheel Drive1
2000–2008ToyotaCorolla Saloon (_E12_)1.8 (ZZE131)Petrol · 127 kW · 1.8L · 4-cylFront-Wheel Drive1
2000–2008ToyotaCorolla Saloon (_E12_)1.8 (ZZE130)Petrol · 97 kW · 1.8L · 4-cylFront-Wheel Drive1
2001–2008ToyotaCorolla (_E12_)1.8 VVTL-i TS (ZZE123_, ZZE123R)Petrol · 160 kW · 1.8L · 4-cylFront-Wheel Drive1
  • Note 1: Height adjustable on the front and rear axles (threaded strut housings).
