KW Coilover Kit V3 for Audi (B8) A4 Avant / A4 Allroad 2.0L TFSI

SKU: 35210077
Sale price$4,692.05 Regular price$4,939.00
Save $246.95

Please note: Not all items are kept in stock. Lead times may apply contact us to confirm availability before ordering.


KW's V3 offers independent adjustment of rebound damping (16 clicks) and compression damping (12 clicks), technology carried over from KW's motorsport programme. KW develops a vehicle-specific base setup on its 7-post rig and in road and track testing, from which the damping can be tuned for comfort or sharper handling. Ride height is continuously adjustable within the tested range. This kit is developed for the Audi A4 Avant / A4 Allroad 2.0 TFSI (B8).

Key Features

  • Rebound damping adjustable in 16 clicks
  • Compression damping adjustable in 12 clicks
  • Continuous ride height adjustment within the tested range

Specifications

  • Version: V3
  • Damping: Adjustable rebound and compression
  • Material: Stainless steel
  • Front lowering: 25–55 mm
  • Rear lowering: 25–50 mm
  • Front axle load: up to 1,080 kg
  • Rear axle load: up to 1,215 kg
  • Supplied as: Front axle coilover struts, rear axle springs with height adjustment + dampers

Front axle load up to 1,080 kg; Rear axle load up to 1,215 kg.

For vehicles without electronic damper control.

See the Disclaimer tab for reference notes.

YearMakeModelVariantEngineDriveRefs
2009–2017AudiA4 Allroad (B8) 8KH2.0 TFSI quattroPetrol · 155 kW · 2.0L · 4-cylAll-Wheel Drive2, 10, 37, 67
2009–2017AudiA4 Allroad (B8) 8KH2.0 TFSI quattroPetrol · 162 kW · 2.0L · 4-cylAll-Wheel Drive2, 10, 37, 67
2009–2017AudiA4 Allroad (B8) 8KH2.0 TFSI quattroPetrol · 165 kW · 2.0L · 4-cylAll-Wheel Drive2, 10, 37, 67
2007–2017AudiA4 Avant (B8) 8K51.8 TFSIPetrol · 88 kW · 1.8L · 4-cylFront-Wheel Drive2, 10, 37, 67
2007–2017AudiA4 Avant (B8) 8K51.8 TFSIPetrol · 118 kW · 1.8L · 4-cylFront-Wheel Drive2, 10, 37, 67
2007–2017AudiA4 Avant (B8) 8K51.8 TFSIPetrol · 125 kW · 1.8L · 4-cylFront-Wheel Drive2, 10, 37, 67
2007–2017AudiA4 Avant (B8) 8K51.8 TFSI quattroPetrol · 118 kW · 1.8L · 4-cylAll-Wheel Drive2, 10, 37, 67
2007–2017AudiA4 Avant (B8) 8K51.8 TFSI quattroPetrol · 125 kW · 1.8L · 4-cylAll-Wheel Drive2, 10, 37, 67
2007–2017AudiA4 Avant (B8) 8K52.0 TDIDiesel · 88 kW · 2.0L · 4-cylFront-Wheel Drive2, 10, 37, 67
2007–2017AudiA4 Avant (B8) 8K52.0 TDIDiesel · 100 kW · 2.0L · 4-cylFront-Wheel Drive2, 10, 37, 67
2007–2017AudiA4 Avant (B8) 8K52.0 TDIDiesel · 105 kW · 2.0L · 4-cylFront-Wheel Drive2, 10, 37, 67
2007–2017AudiA4 Avant (B8) 8K52.0 TDIDiesel · 110 kW · 2.0L · 4-cylFront-Wheel Drive2, 10, 37, 67
2007–2017AudiA4 Avant (B8) 8K52.0 TDIDiesel · 120 kW · 2.0L · 4-cylFront-Wheel Drive2, 10, 37, 67
2007–2017AudiA4 Avant (B8) 8K52.0 TDIDiesel · 125 kW · 2.0L · 4-cylFront-Wheel Drive2, 10, 37, 67
2007–2017AudiA4 Avant (B8) 8K52.0 TDIDiesel · 130 kW · 2.0L · 4-cylFront-Wheel Drive2, 10, 37, 67
2007–2017AudiA4 Avant (B8) 8K52.0 TFSIPetrol · 132 kW · 2.0L · 4-cylFront-Wheel Drive2, 10, 37, 67
2007–2017AudiA4 Avant (B8) 8K52.0 TFSIPetrol · 155 kW · 2.0L · 4-cylFront-Wheel Drive2, 10, 37, 67
2007–2017AudiA4 Avant (B8) 8K52.0 TFSIPetrol · 165 kW · 2.0L · 4-cylFront-Wheel Drive2, 10, 37, 67
2007–2017AudiA4 Avant (B8) 8K52.0 TFSI quattroPetrol · 155 kW · 2.0L · 4-cylAll-Wheel Drive2, 10, 37, 67
2007–2017AudiA4 Avant (B8) 8K52.0 TFSI quattroPetrol · 165 kW · 2.0L · 4-cylAll-Wheel Drive2, 10, 37, 67
  • Note 2: Height adjustable front and rear axles (front axle threaded strut housings, rear axle adjustable springs + dampers).
  • Note 10: In Variant 2, hardness adjustment for front axle only in not installed condition possible.
  • Note 37: For cars which have electronic dampers, make sure they are shut down. Specific electronical damper shut-downs are available from KW. Please check our accessories list.
  • Note 67: Dampers are adjusted by easily operating adjustment wheels. Rebound is only adjustable if the top of the piston rod is accessible. This will depend on the vehicle construction.
