KW Coilover Kit V3 for BMW (E70) X5 M / (E71) X6 M

SKU: 35220079
Sale price$5,632.55 Regular price$5,929.00
Save $296.45

Please note: Not all items are kept in stock. Lead times may apply contact us to confirm availability before ordering.


KW's V3 offers independent adjustment of rebound damping (16 clicks) and compression damping (12 clicks), technology carried over from KW's motorsport programme. KW develops a vehicle-specific base setup on its 7-post rig and in road and track testing, from which the damping can be tuned for comfort or sharper handling. Ride height is continuously adjustable within the tested range. This kit is developed for the BMW X5 M (E70) / X6 M (E71).

Key Features

  • Rebound damping adjustable in 16 clicks
  • Compression damping adjustable in 12 clicks
  • Continuous ride height adjustment within the tested range

Specifications

  • Version: V3
  • Damping: Adjustable rebound and compression
  • Material: Stainless steel
  • Front lowering: 10–45 mm
  • Rear lowering: 10–35 mm
  • Front axle load: up to 1,400 kg
  • Rear axle load: up to 1,560 kg
  • Supplied as: Front axle coilover struts, rear axle dampers
Note For cars with air springs at the rear axle (level control). Without cancellation kit for electronic damper control.

Front axle load up to 1,400 kg; Rear axle load up to 1,560 kg.

For vehicles without electronic damper control.

For cars with air springs at the rear axle (level control).

See the Disclaimer tab for reference notes.

YearMakeModelVariantEngineDriveNotesRefs
2006–2013BMWX5 (E70) M7X, X-N1, X5, X70MPetrol · 414 kW · 4.4L · 8-cylAll-Wheel DriveWithout cancellation kit electronic damping37, 42
2007–2015BMWX6 (E71, E72) HY, M7X, X-N1, X6, X70MPetrol · 414 kW · 4.4L · 8-cylAll-Wheel DriveWithout cancellation kit electronic damping37, 42
2006–2013BMWX5 (E70) M7X, X-N1, X5, X70MPetrol · 408 kW · 4.4L · 8-cylAll-Wheel DriveWithout cancellation kit electronic damping37, 42
2007–2015BMWX6 (E71, E72) HY, M7X, X-N1, X6, X70MPetrol · 408 kW · 4.4L · 8-cylAll-Wheel DriveWithout cancellation kit electronic damping37, 42
  • Note 37: For cars which have electronic dampers, make sure they are shut down. Specific electronical damper shut-downs are available from KW. Please check our accessories list.
  • Note 42: For the rear axle sport shock absorbers will be supplied, the factory air spring will maintain. The lowering of the vehicle needs to be done according to the instructions.
