KW Coilover Kit V3 for Mini (F56) JCW GP
Please note: Not all items are kept in stock. Lead times may apply contact us to confirm availability before ordering.

KW Coilover Kit V3 for Mini (F56) JCW GP
Sale price$4,597.05
Regular price$4,839.00 (/)
KW's V3 offers independent adjustment of rebound damping (16 clicks) and compression damping (12 clicks), technology carried over from KW's motorsport programme. KW develops a vehicle-specific base setup on its 7-post rig and in road and track testing, from which the damping can be tuned for comfort or sharper handling. Ride height is continuously adjustable within the tested range. This kit is developed for the Mini JCW GP (F56).
Key Features
- Rebound damping adjustable in 16 clicks
- Compression damping adjustable in 12 clicks
- Continuous ride height adjustment within the tested range
Specifications
- Version: V3
- Damping: Adjustable rebound and compression
- Material: Stainless steel
- Front lowering: 10–25 mm
- Rear lowering: 10–25 mm
- Front axle load: up to 920 kg
- Rear axle load: up to 615 kg
- Supplied as: Front axle coilover struts, rear axle springs with height adjustment + dampers
Front axle load up to 920 kg; Rear axle load up to 615 kg.
See the Disclaimer tab for reference notes.
| Year | Make | Model | Variant | Engine | Drive | Refs |
|---|---|---|---|---|---|---|
| 2013+ | Mini | Mini (F56) FML2, UKL-L | John Cooper Works GP | Petrol · 225 kW · 2.0L · 4-cyl | Front-Wheel Drive | 2, 67, 85 |
- Note 2: Height adjustable front and rear axles (front axle threaded strut housings, rear axle adjustable springs + dampers).
- Note 67: Dampers are adjusted by easily operating adjustment wheels. Rebound is only adjustable if the top of the piston rod is accessible. This will depend on the vehicle construction.
- Note 85: For rear axle camber adjustment we recommend the installation of the car specific adjustable control arm set from KW. The part number for the control arm set is mention in the accessories list.
