ST Coilover X Kit for VW (MK8) Golf GTI / GTI Clubsport / R
Please note: Not all items are kept in stock. Lead times may apply contact us to confirm availability before ordering.

ST Coilover X Kit for VW (MK8) Golf GTI / GTI Clubsport / R
Sale price$1,630.30
Regular price$2,329.00 (/)
ST X coilovers give continuous ride height adjustment on galvanised, multi-sealed struts via a polyamide adjuster ring. Manufactured by KW Automotive, they use twin-tube dampers with a fixed, vehicle-specific setting, a low-friction pressure-resistant housing, chrome-plated piston rod and a monobloc guide with ST seal package to keep dirt out in all weather. This kit is developed for the VW Golf VIII (CD1).
Key Features
- Galvanised coilover struts
- Fixed, vehicle-specific damping
- Manufactured by KW Automotive
Specifications
- Version: X
- Damping: Fixed, vehicle-specific setting
- Material: Galvanised steel
- Front lowering: 25–45 mm
- Rear lowering: 25–45 mm
- Front axle load: up to 1,110 kg
- Rear axle load: up to 990 kg
- Front strut diameter (vehicle): 55 mm
- Supplied as: Front axle coilover struts, rear axle springs with height adjustment + dampers
Front axle load up to 1,110 kg; Rear axle load up to 990 kg.
See the Disclaimer tab for reference notes.
| Year | Make | Model | Variant | Engine | Drive | Refs |
|---|---|---|---|---|---|---|
| 2019+ | VW | Golf VIII (CD1, DA1) | 2.0 GTI | Petrol · 180 kW · 2.0L · 4-cyl | Front-Wheel Drive | 71, 209 |
| 2019+ | VW | Golf VIII (CD1, DA1) | 2.0 GTI | Petrol · 195 kW · 2.0L · 4-cyl | Front-Wheel Drive | 71, 209 |
| 2019+ | VW | Golf VIII (CD1, DA1) | 2.0 GTI 50 | Petrol · 239 kW · 2.0L · 4-cyl | Front-Wheel Drive | 71, 209 |
| 2019+ | VW | Golf VIII (CD1, DA1) | 2.0 GTI Clubsport | Petrol · 221 kW · 2.0L · 4-cyl | Front-Wheel Drive | 71, 209 |
| 2019+ | VW | Golf VIII (CD1, DA1) | 2.0 TSI R 4motion | Petrol · 235 kW · 2.0L · 4-cyl | All-Wheel Drive | 71, 209 |
| 2019+ | VW | Golf VIII (CD1, DA1) | 2.0 TSI R 4motion | Petrol · 245 kW · 2.0L · 4-cyl | All-Wheel Drive | 71, 209 |
- Note 71: Only for cars with a clamp diameter of 55 mm on the front axle.
- Note 209: At vehicles equipped with electronic damping, the electronic damping control needs to be deactivated. Deactivation kit KW Part-no. 68510342.
