ST Coilovers ST X galvanized steel (with fixed damping) AUDI A3 (8V1, 8VK) 04/2012- (1321000N)

SKU: 1321000N
Sale price$2,049.00

Description


Coilovers ST X galvanized steel (with fixed damping)

Need to get low? ST coilovers feature a continuous thread construction for height adjustment from moderate to eXtreme! Each coilover is manufactured by KW Automotive and their expertise and know how ensures maximum quality and fantastic driving dynamics.

Once installed, the ST X coilover can be easily adjusted using a polyamide ring on the galvanized, multiple-sealed strut. Adjustment is different for each car, but typically you can expect between 35 and 65mm of lowering on both the front and rear axles. For lowered cars as standard (such as the BMW E9x 3-series) the ST X coilover features a range of 30 to 60mm (front axle) and 25-55mm (rear axle).


Improved driving dynamics and handling
Designed in conjunction with KW Germany, ST X coilovers deliver a sporty handling by reducing the carÕs bodyroll during compression as well as improving agility when driving fast. The high-quality production of each ST X coilover includes a low-friction and pressure resistant housing alongside a chrome-plated piston rod for maximum longevity. A mono block guide and ST seal package ensures the twin-tube dampers remain free of dirt particles in all weather conditions.

Lowering with St\Tyle: the ST X coilovers
- Individual lowering within the tested adjustment range
- Front and rear axle thread adjustment (when possible)
- Galvanized coilover struts with additional coating for optimized corrosion protection
- Complete solution with adjustable spring plate, spring system and bumpers with dust protection
- Powerful twin-tube dampers with high-quality components for maximum longevity


Product Disclaimers:

  • Note 226: At vehicles equipped with electronic damping, the electronic damping control needs to be deactivated. Deactivation kit KW Part-no. 68510424
  • Note 71: Only for cars with a clamp diameter of 55 mm on the front axle

Fitments

Make Model Type Body Type Aspiration KW CCM Cyl Drivetrain
AUDI A3 (8V) 8V1, 8VK 04/2012-10/2020 1.0 TFSI Hatchback Petrol 85 999 3 Front Wheel Drive
AUDI A3 (8V) 8V1, 8VK 04/2012-10/2020 1.2 TFSI Hatchback Petrol 77 1197 4 Front Wheel Drive
AUDI A3 (8V) 8V1, 8VK 04/2012-10/2020 1.2 TFSI Hatchback Petrol 81 1197 4 Front Wheel Drive
AUDI A3 (8V) 8V1, 8VK 04/2012-10/2020 1.4 TFSI Hatchback Petrol 90 1395 4 Front Wheel Drive
AUDI A3 (8V) 8V1, 8VK 04/2012-10/2020 1.4 TFSI Hatchback Petrol 92 1395 4 Front Wheel Drive
AUDI A3 (8V) 8V1, 8VK 04/2012-10/2020 1.4 TFSI Hatchback Petrol 103 1395 4 Front Wheel Drive
AUDI A3 (8V) 8V1, 8VK 04/2012-10/2020 1.4 TSI Hatchback Petrol 110 1395 4 Front Wheel Drive
AUDI A3 (8V) 8V1, 8VK 04/2012-10/2020 1.5 TFSI Hatchback Petrol 110 1495 4 Front Wheel Drive
AUDI A3 (8V) 8V1, 8VK 04/2012-10/2020 1.6 TDI Hatchback Diesel 81 1598 4 Front Wheel Drive
AUDI A3 (8V) 8V1, 8VK 04/2012-10/2020 1.8 TFSI Hatchback Petrol 132 1798 4 Front Wheel Drive
AUDI A3 (8V) 8V1, 8VK 04/2012-10/2020 2.0 TDI Hatchback Diesel 81 1968 4 Front Wheel Drive
AUDI A3 Saloon (8V) 8VS, 8VM 05/2013-10/2020 1.0 TFSI Saloon Petrol 85 999 3 Front Wheel Drive
AUDI A3 Saloon (8V) 8VS, 8VM 05/2013-10/2020 1.2 TFSI Saloon Petrol 77 1197 4 Front Wheel Drive
AUDI A3 Saloon (8V) 8VS, 8VM 05/2013-10/2020 1.2 TFSI Saloon Petrol 81 1197 4 Front Wheel Drive
AUDI A3 Saloon (8V) 8VS, 8VM 05/2013-10/2020 1.4 TFSI Saloon Petrol 90 1395 4 Front Wheel Drive
AUDI A3 Saloon (8V) 8VS, 8VM 05/2013-10/2020 1.4 TFSI Saloon Petrol 92 1395 4 Front Wheel Drive
AUDI A3 Saloon (8V) 8VS, 8VM 05/2013-10/2020 1.4 TFSI Saloon Petrol 103 1395 4 Front Wheel Drive
AUDI A3 Saloon (8V) 8VS, 8VM 05/2013-10/2020 1.4 TSI Saloon Petrol 110 1395 4 Front Wheel Drive
AUDI A3 Saloon (8V) 8VS, 8VM 05/2013-10/2020 1.5 TFSI Saloon Petrol 110 1495 4 Front Wheel Drive
AUDI A3 Saloon (8V) 8VS, 8VM 05/2013-10/2020 1.8 TFSI Saloon Petrol 125 1798 4 Front Wheel Drive
AUDI A3 Saloon (8V) 8VS, 8VM 05/2013-10/2020 2.0 TDI Saloon Diesel 81 1968 4 Front Wheel Drive
AUDI A3 Saloon (8V) 8VS, 8VM 05/2013-10/2020 2.0 TDI Saloon Diesel 105 1968 4 Front Wheel Drive
AUDI A3 Saloon (8V) 8VS, 8VM 05/2013-10/2020 2.0 TFSI Saloon Petrol 137 1984 4 Front Wheel Drive
AUDI A3 Saloon (8V) 8VS, 8VM 05/2013-10/2020 2.0 TFSI Saloon Petrol 162 1984 4 Front Wheel Drive
AUDI A3 Saloon (8V) 8VS, 8VM 05/2013-10/2020 30 TDI Saloon Diesel 85 1598 4 Front Wheel Drive
AUDI A3 Saloon (8V) 8VS, 8VM 05/2013-10/2020 30 TFSI Saloon Petrol 85 999 3 Front Wheel Drive
AUDI A3 Saloon (8V) 8VS, 8VM 05/2013-10/2020 35 TFSI Saloon Petrol 110 1495 4 Front Wheel Drive
AUDI A3 Saloon (8V) 8VS, 8VM 05/2013-10/2020 40 TFSI Saloon Petrol 140 1984 4 Front Wheel Drive
AUDI A3 Sportback (8V) 8VA, 8VF 09/2012-10/2020 1.0 TFSI Hatchback Petrol 85 999 3 Front Wheel Drive
AUDI A3 Sportback (8V) 8VA, 8VF 09/2012-10/2020 1.2 TFSI Hatchback Petrol 77 1197 4 Front Wheel Drive
AUDI A3 Sportback (8V) 8VA, 8VF 09/2012-10/2020 1.2 TFSI Hatchback Petrol 81 1197 4 Front Wheel Drive
AUDI A3 Sportback (8V) 8VA, 8VF 09/2012-10/2020 1.4 TFSI Hatchback Petrol 90 1395 4 Front Wheel Drive
AUDI A3 Sportback (8V) 8VA, 8VF 09/2012-10/2020 1.4 TFSI Hatchback Petrol 92 1395 4 Front Wheel Drive
AUDI A3 Sportback (8V) 8VA, 8VF 09/2012-10/2020 1.4 TFSI Hatchback Petrol 103 1395 4 Front Wheel Drive
AUDI A3 Sportback (8V) 8VA, 8VF 09/2012-10/2020 1.4 TSI Hatchback Petrol 110 1395 4 Front Wheel Drive
AUDI A3 Sportback (8V) 8VA, 8VF 09/2012-10/2020 1.5 TFSI Hatchback Petrol 110 1495 4 Front Wheel Drive
AUDI A3 Sportback (8V) 8VA, 8VF 09/2012-10/2020 2.0 TDI Hatchback Diesel 81 1968 4 Front Wheel Drive
AUDI A3 Sportback (8V) 8VA, 8VF 09/2012-10/2020 2.0 TDI Hatchback Diesel 105 1968 4 Front Wheel Drive
AUDI A3 Sportback (8V) 8VA, 8VF 09/2012-10/2020 30 TDI Hatchback Diesel 85 1598 4 Front Wheel Drive
AUDI A3 Sportback (8V) 8VA, 8VF 09/2012-10/2020 30 TFSI Hatchback Petrol 85 999 3 Front Wheel Drive
AUDI A3 Sportback (8V) 8VA, 8VF 09/2012-10/2020 35 TFSI Hatchback Petrol 110 1495 4 Front Wheel Drive
AUDI A3 Sportback (8V) 8VA, 8VF 09/2012-10/2020 40 TFSI Hatchback Petrol 140 1984 4 Front Wheel Drive

Parts Approval: PDF

Installation Instruction: PDF
