ST Wheel Spacer System A1 40mm per Axle 5x114.3/66.1

SKU: 56010231
Sale price$407.55 Regular price$429.00
Save $21.45

Please note: Not all items are kept in stock. Lead times may apply contact us to confirm availability before ordering.


ST's A1 is a bolt-on wheel spacer system for vehicles with wheel bolts. The spacers attach to the hub with the included bolts, and the wheel is then fitted to the spacer using the original wheel bolts.

Key Features

  • Black anodised for corrosion protection
  • Wider track for a more planted stance

Specifications

  • Width: 40 mm per axle (20 mm per wheel)
  • Bolt pattern (PCD): 5x114.3
  • Centre bore: 66.1 mm
  • Mounting: Bolt-on (spacer bolts to the hub; wheel fits to the spacer)
  • Centring collar: Yes
  • Vehicle wheel fastening: Wheel bolts, M12x1.5
  • Position: Front or rear axle
  • Material: Aluminium
  • Supplied as: Set (2 pcs including wheel bolts)

Wheel mounting

Bolt pattern5x114.3
Hub bore66.1mm
Width per axle40mm
SystemA1
ThreadBolt: M12x1.5x26 Taper 60°, 17mm wrench size
Wheel offset limit34
MaterialAluminium
Supplied asSet (2 pcs. incl. wheel bolts)
  • Note 302: Wheel arch needs to be rolled / modified.
